Preliminary Data Sheet

VS-750

Dual Frequency VCSO

Features

鈥?/div>

5 x 7.5 x 2.5 mm Package

鈥?/div>

Output Frequencies from 500 MHz to 850 MHz

鈥?/div>

3.3 V Operation

鈥?/div>

Low Jitter < 0.25 ps-rms across 50 kHz to 80 MHz

鈥?/div>

LV-PECL Configuration with Fast Transition Times

鈥?/div>

Complementary Outputs

鈥?/div>

Frequency Select

鈥?/div>

Output Disable

鈥?/div>

Patent Pending Technology

鈥?/div>

Fully Compatible for Lead Free Assembly

Applications

PLL circuits for Clock Smoothing and Frequency Translation

Description

鈥?/div>

1-2-4 Gigabit Fibre Channel

鈥?/div>

10 Gigabit Fibre Channel

鈥?/div>

10GbE LAN / WAN

鈥?/div>

OC-192

鈥?/div>

SONET / SDH

Vcc

COutput

Output

Standard

INCITS 352-2002

INCITS 364-2003

IEEE 802.3ae

ITU-T G.709

GR-253-CORE Issue3

Description

SAW 1

SAW 2

Gnd

The VS-750 is a SAW based voltage controlled oscillator that

operates at the fundamental frequencies of the internal SAW

filters. These SAW filters are high-Q quartz devices that

enable the circuit to achieve low phase jitter performance over

a wide operating temperature range. The dual oscillator is

housed in a hermetically sealed leadless surface mount

package offered on tape and reel. It has a frequency select

function that enables either 鈥淔requency 1鈥?or 鈥淔requency 2.鈥?It

also has an output disable to facilitate on-board testing.

Tel: 1-88-VECTRON-1

Website: www.vectron.com

Rev: 03Mar05

Vectron International, 267 Lowell Rd, Hudson NH 03051-4916

Page 1 of 7
