VRE204MA Datasheet

  • VRE204MA

  • Precision Surface Mount Reference Supply

  • 200.94KB

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

VRE204
Precision Surface Mount
Reference Supply
THALER CORPORATION 鈥?2015 N. FORBES BOULEVARD 鈥?TUCSON, AZ. 85745 鈥?(520) 882-4000
FEATURES
鈥?/div>
VERY HIGH ACCURACY: 4.5000 V OUTPUT 鹵0.4 mV
鈥?/div>
EXTREMELY LOW DRIFT: 0.6 ppm/擄C -55擄C to +125擄C
鈥?/div>
EXCELLENT STABILITY: 6ppm/1000 Hrs. Typ.
鈥?/div>
EXCELLENT LINE REGULATION: 6 ppm/V Typ.
鈥?/div>
WIDE SUPPLY RANGE: +13.5 V to +22.0 V
鈥?/div>
HERMETIC 20 TERMINAL CERAMIC LCC
鈥?/div>
MILITARY PROCESSING AVAILABLE
APPLICATIONS
鈥?/div>
PRECISION A/D and D/A CONVERTERS
鈥?/div>
TRANSDUCER EXCITATION
鈥?/div>
ACCURATE COMPARATOR THRESHOLD
REFERENCE
鈥?/div>
HIGH RESOLUTION SERVO SYSTEMS
鈥?/div>
DIGITAL VOLTMETERS
鈥?/div>
HIGH PRECISION TEST and
MEASUREMENT INSTRUMENTS
DESCRIPTION
VRE204 Series Precision Voltage References
provide ultrastable +4.500 V outputs with up to
鹵0.4 mV initial accuracy and temperature
coefficient as low as 0.6 ppm/擄C over the full
military temperature range.
These references are specifically designed to be
used with the Crystal Semiconductor line of
successive-approximation type Analog-to-Digital
Converters (ADCs). This line of ADCs sets new
standards for temperature drift, which can only be
as good as the external reference used. The
Thaler VRE204 combined with a Crystal ADC will
provide the lowest drift data conversion
obtainable.
SELECTION GUIDE
Type
Output
Temperature
Max. Volt
Operating Range Deviation
-25擄C to +85擄C
-25擄C to +85擄C
-55擄C to +125擄C
-55擄C to +125擄C
0.4mV
0.2mV
0.6mV
0.3mV
VRE204C
+4.5V
VRE204CA +4.5V
VRE204M +4.5V
VRE204MA +4.5V
VRE204 series devices are available in two operating temperature ranges, -25擄C to +85擄C and -55擄C to
+125擄C, and two performance grades. All devices are packaged in 20 terminal LCC ceramic packages
for maximum long-term stability. "M" versions are screened for high reliability and quality.
Superior stability, accuracy, and quality make the VRE204 ideal for all precision applications which may
require a 4.5V reference. High-accuracy test and measurement instrumentation, and transducer
excitation are some other applications which can benefit from the high accuracy of the VRE204.
VRE204DS REV. C JUNE 1995

VRE204MA 產品屬性

  • Cirrus Logic

  • 基準電壓& 基準電流

  • Voltage References

  • Series References

  • Precision

  • 4.5 V

  • 0.8 mV

  • 0.6 PPM / C

  • 22 V

  • 8 mA

  • + 125 C

  • CLCC-20

  • - 55 C

  • SMD/SMT
