V 4373 System Controller
RC
Data Sheet
October 1997
1.0
1.1
Introduction
The V
RC
4373
TM
system controller is a software-configurable chip that directly interfaces
the V
R
4300
TM
CPU and PCI bus without external logic or buffering, and also interfaces
memory (SDRAM, EDO, fast-page DRAM, and flash boot ROM) with minimal buffer-
ing. From the viewpoint of the V
R
4300 CPU, the V
RC
4373 acts as a memory controller,
DMA controller, and PCI bridge. From the viewpoint of PCI agents, the V
RC
4373 acts
as either a PCI bus master or a PCI bus target. Alternatively, the V
RC
4373 may be
located on a PCI bus add-on board.
Overview
1.2
q
CPU Interface
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Direct connection to the 66MHz V
R
4300 CPU bus
3.3V I/O
Support for all V
R
4300 bus cycles
Little-endian or big-endian byte order
Support for boot ROM, base memory, and up to four SIMM
TM
(DIMM) ranges
Programmable address ranges for base memory and SIMM memory
66 MHz memory bus
Base memory range: SDRAM and EDO DRAM
SIMM memory range: SDRAM, EDO and fast-page DRAM, and flash ROM
Several speed grades supported within each memory range
Bank-interleaved or non-bank-interleaved SIMM memory ranges
On-chip bank-interleaving buffers
Open DRAM page maintained within base memory
8-word (32-byte) write FIFO (CPU-to-memory)
2-word (8-byte) prefetch FIFO (memory-to-CPU or memory-to-PCI)
On-chip DRAM and SDRAM refresh generation
Up to 16 MB of write-protectable boot ROM
Boot ROM address and data signals multiplexed on DRAM data signals
3.3V inputs; 5V-tolerant outputs
Master and target capability
Host bridge and add-on board modes
PCI bus arbiter
4-word (16-byte) bidirectional PCI master FIFO (CPU = PCI bus master)
Features
q
Memory Interface
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
q
PCI Interface
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
U13023EU1V0DSU1
