AudioCoded
TM
Enabling Technology Products
VoicePacketizer
TM
Voice over IP Streaming Protocol Stack
AudioCodes'
VoicePacketizer
TM
is a highly portable ANSI C language software
application library implementing RTP/RTCP encapsulation per RFC
VoicePacketizer
TM
1.xx Schematic Diagram
OS
1889/1890/2198/2833. It has been tested to be compatible with most of
the popular communication processors and embedded operating systems.
The VoicePacketizer
TM
is compliant and easy to integrate with the widely
available software stacks (e.g. H.323, SIP). The VoicePacketizer
TM
typically
runs on the master communication processor of a VoIP gateway, access
multiplexer, or other packet network access or switching equipment.
User聮s Application
IP Network
RTP/RTCP
decoder
RTP/RTCP
encoder
Easy Integration to Gateway Application
A VoIP gateway application consists of two main components: a call setup
and signaling module and a stream processing module. The two are linked
by the application layer. The VoicePacketizer
TM
provides all stream processing
functions while the call setup and signaling modules can be purchased from
third party. The standard RTP/RTCP is extended to support a variety of voice
coders: G.711. G.726, G.727, G.723.1, G.729A/B and the NetCoder as well
as G3 fax relay (based on T.38) and DTMF relay (RFC 2833). The
VoicePacketizer
TM
provides also the API for all DSP functionalities: Download,
PCM
Voice/Fax
Jitter Buffer
VoicePacketizer
TM
Stack
AC48xx Drivers
Interrupt
Initialization and Setup, and run time configuration.
Convenient Functions for Fast Start-up
Voice/Fax Packets
AC48xx
VoP Processor
Convenient Functions are a small set of functions, providing users with
simplified API containing larger building blocks to enable quick application
construction. Using the Convenient Functions, users do not need to directly
use the Initialization and Setup functions, AC48xx driver functions and most
of the Media Streaming Functions. These functions may also serve as a
reference code in case users want to use the basic VoicePacketizer
TM
stack聮s
function set. An application demo program is provided to show how to use
the Convenient Functions.
樓
Enables fast integration of VoP processors
樓
Minimizes development risks
樓
Field-proven in real networks
Benefit from Extensive Experience
AudioCodes is one of the world's leading providers of VoP DSP solutions since
1996. During this period, the company successfully passed numerous
interoperability tests while maintaining high levels of performance. AudioCodes'
commitment to innovation yields consistently high-quality voice processing
products that are feature-rich and field-proven. AudioCodes has deployed
more than 5 million VoP ports to date.
