鈩?/div>
I
OUT
1.6 A
V
CC
26 V
s
s
s
s
s
s
OUTPUT CURRENT (CONTINUOUS):
9A @ T
c
= 85
o
C PER CHANNEL
5V LOGIC LEVEL COMPATIBLE INPUT
THERMAL SHUT-DOWN
UNDER VOLTAGE PROTECTION
OPEN DRAIN DIAGNOSTIC OUTPUT
INDUCTIVE LOAD FAST
DEMAGNETIZATION
VERY LOW STAND-BY POWER
DISSIPATION
10
1
DESCRIPTION
The VND05BSP is a monolithic device made
using STMicroelectronics VIPower Technology,
intended for driving resistive or inductive loads
with one side grounded. This device has two
channels, and a common diagnostic. Built-in
thermal shut-down protects the chip from over
temperature and short circuit.
The status output provides an indication of open
load in on
state, open load in off state,
overtemperature conditions and stuck-on to V
CC
.
BLOCK DIAGRAM
PowerSO-10
April 2001
1/9
