廬

VN380

VN380SP

SMART SOLENOID DRIVER

SOLID STATE RELAY

T YPE

VN380

VN380SP

loa d(cl)

60 V

5 A

0.11

鈩?/div>

0.11

鈩?/div>

LOAD CURRENT UP TO 7 A

CMOS COMPATIBLE

THERMAL SHUTDOWN

DIGNOSTIC OUTPUT

INTEGRATED CLAMPS

OVER CURRENT PROTECTION

OPEN COIL DETECTION

OVER VOLTAGE DECTION

DESCRIPTION

The VN380 is a monolithic device made using

STM VIPower Technology, intended for driving

inductive loads. The inputs are CMOS

compatible. The diagnostic output provides an

indication of open load and demagnetization

mode. Built-in thermal shut-down protects the

chip from over-temperature. In case or

over-current or over-temperature or over-voltage

the product will automatically operate in

recirculation mode.

BLOCK DIAGRAM

HEPTAWATT

PowerSO-1O

ORDER CODES:

HEPTAWATT

VN380

PowerSO-1O

VN380SP

June 1998

1/9
