VN340-8933 Datasheet

  • VN340-8933

  • QUAD HIGH SIDE SMART POWER SOLID STATE RELAY

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
VN340SP(8933)
QUAD HIGH SIDE SMART
POWER SOLID STATE RELAY
TYPE
V
demag
(*)
R
DSon
(*)
I
OUT
(*)
V
CC
VN340SP(8933) V
CC
-55V
0.2鈩?/div>
1A
36 V
(*) Per channel
n
OUTPUT CURRENT: 1A PER CHANNEL
n
DIGITAL I/O鈥檚 CLAMPED AT 32V MINIMUM
VOLTAGE
n
PROTECTION AGAINST SHORTED LOAD
AND OVERTEMPERATURE
n
BUILT-IN CURRENT LIMITER
n
UNDER VOLTAGE SHUT DOWN
n
OPEN DRAIN DIAGNOSTIC OUTPUT
n
FAST DEMAGNETIZATION OF INDUCTIVE
LOADS
n
CONFORMS TO IEC 1131-2
10
1
PowerSO-10
TM
DESCRIPTION
The VN340SP(8933) is a monolithic device made
using STMicroelectronics VIPower technology,
intended for driving four indipendent resistive or
inductive loads with one side connected to
ground. Active current limitation avoids dropping
the system power supply in case of shorted load.
BLOCK DIAGRAM
Built-in thermal shut down protects the chip from
overtemperature and short circuit. The open drain
diagnostic output indicates overtemperature
conditions. Each I/O is pulled down when
overtemperature condition of the relative channel
is verified.
June 2001
1/10
1
