HYBRID IC
VLA106-15151
ISOLATED TYPE DC-DC CONVERTER
DESCRIPTION
The VLA106-15151 is a DC-DC converter. Its output
power is 1.5W and the input is isolated from the output.
The over-current protection circuit is built-in and it is the
best for on-board power supplies, such as industrial
equipment and control equipment.
33.0 MAX
OUTLINE DRAWING
Dimensions: mm
FEATURES
鈥nput voltage range: 12 to 18V DC
鈥utput: +15V, 100mA (output power : 1.5W)
鈥hin-profile and lightweight design
鈥solation between input and output : 2500Vrms, 1min
鈥uilt-in over-current protection circuit
15151
XXXX
24.0 MAX
5.5 MAX
4.5 MAX
2.54 x 10=25.4
4.5 MAX
13.5 MAX
18 MAX
APPLICATIONS
On-board power supplies, such as industrial equipment
and control equipment.
1
11
BLOCK DIAGRAM
+V
IN
8
9
FILTER
FILTER
3
CONSTANT
VOLTAGE
CIRCUIT
+V
O
2
NC
DRIVE
CIRCUIT
1
-V
O
-V
IN
10
11
OVER-CURRENT
PROTECTION
OPTO COUPLER
