Vestigial Sideband Filters

VESTIGIAL SIDEBAND FILTERS

For Professional Applications

Replaces August 1992, version CT3447-1.2

DS5513-1.0 January 2002

Dynex Semiconductor's range of Surface Acoustic Wave

filters provide IF filtering for most current TV systems. The

filters are designed for use in TV modulators and transposers,

and are available without sound, with one sound channel, or

with stereo sound.

FEATURES

s

Filters for System B/G, I, M & K TV Standards

s

Linear Phase Characteristics

s

Low Amplitude and Group Delay Ripple

s

Sidelobe Levels Better Than 50dB

s

Hermetically Sealed Package

FILTER

DW1401-G

DW1404-G

DW1406-G

DW1408-G

DW1409-G

DW1411-G

DW2501-G

DW1502-I

DW1503-I

DW1505-I

DW9231-I

DW9232-I

DW1603-M

DW1605-M

DW1701-K

DW1702-K

SYSTEM

B/G

B/G

B/G

B/G

B/G

B/G

B/G

I

I

I

I

I

M

M

K

K

SOUND

None

1

None

Stereo

Stereo

None

1

1

1

1

None

None

1

None

1

REMARKS

PACKAGE STYLE

A

A

A

A

D

A

A

A

A

A

D

D

D

D

A

A

NICAM Sound Filter

NICAM Vision Filter

1/8

www.dynexsemi.com
