V950ME01
9939 Via Pasar 鈥?San Diego, CA 92126
TEL (619) 621-2700 FAX (619) 621-2722
VOLTAGE CONTROLLED OSCILLATOR
Rev A1
PHASE NOISE (1 Hz BW, typical)
-54
-64
-74
-84
FEATURES
鈥?Frequency Range: 4420
-
4620 MHz
鈥?Tuning Voltage:
1.5-11 Vdc
鈥?MINI-14S-L - Style Package
APPLICATIONS
鈥?Microwave Radios
鈥?Satellite Communications
鈥?Direct Broadcast
PERFORMANCE SPECIFICATIONS
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW, typ.)
Harmonic Suppression (2nd, typ.)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance (max.)
Pushing
Pulling (14 dB Return Loss, Any Phase)
-94
-104
-114
1K
10K
100K
VALUE
4420
-
4620
-85
-15
1.5-11
36
0鹵3
50
50
<10
<20
-35 to 80
MINI-14S-L
UNITS
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
鈩?/div>
pF
MHz/V
MHz
擄C
Operating Temperature Range
Package Style
POWER SUPPLY REQUIREMENTS
Supply Voltage (Vcc, nom.)
Supply Current (Icc, typ.)
5
14
APPLICATION NOTES
Vdc
mA
All specifications are typical unless otherwise noted and subject to change without notice.
鈥?/div>
AN-100/1 : Mounting and Grounding of VCOs
鈥?/div>
AN-102 : Proper Output Loading of VCOs
鈥?/div>
AN-107 : How to Solder Z-COMM VCOs
NOTES:
Phase Noise @ 100 kHz offset (1 Hz BW, typ.): -110 dBc/Hz
漏 Z-Communications, Inc.
Page 1
All rights reserved
