V900ME01
9939 Via Pasar 鈥?San Diego, CA 92126
TEL (619) 621-2700 FAX (619) 621-2722
VOLTAGE CONTROLLED OSCILLATOR
Rev C3
PHASE NOISE (1 Hz BW, typical)
-20
-40
-60
-80
FEATURES
鈥?Frequency Range: 3500
-
4000 MHz
鈥?Tuning Voltage:
2-18 Vdc
鈥?MINI-14H - Style Package
APPLICATIONS
鈥?Direct Broadcast
鈥?Microwave Radios
鈥?Earthstations
PERFORMANCE SPECIFICATIONS
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW, typ.)
Harmonic Suppression (2nd, typ.)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance (max.)
Pushing
Pulling (14 dB Return Loss, Any Phase)
-140
10
0
1
K
1K
0
100K
-100
-120
VALUE
3500
-
4000
-90
-20
2-18
40
6鹵3
50
50
<7
<20
-20 to 60
MINI-14H
UNITS
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
鈩?/div>
pF
MHz/V
MHz
擄C
Operating Temperature Range
Package Style
POWER SUPPLY REQUIREMENTS
Supply Voltage (Vcc, nom.)
Supply Current (Icc, typ.)
8
26
APPLICATION NOTES
Vdc
mA
All specifications are typical unless otherwise noted and subject to change without notice.
鈥?/div>
AN-100/1 : Mounting and Grounding of VCOs
鈥?/div>
AN-102 : Proper Output Loading of VCOs
鈥?/div>
AN-107 : How to Solder Z-COMM VCOs
NOTES:
漏 Z-Communications, Inc.
Page 1
All rights reserved
