V620TE01
9939 Via Pasar 鈥?San Diego, CA 92126
TEL (858) 621-2700 FAX (858) 621-2722
VOLTAGE CONTROLLED OSCILLATOR
Rev A1
PHASE NOISE (1 Hz BW, typical)
-60
-80
-100
FEATURES
鈥?Frequency Range: 1210 - 1235
鈥?Tuning Voltage:
1-4.2 Vdc
鈥?375 - Style Package
APPLICATIONS
鈥?UMTS Basestations
鈥?Portable Radios
鈥?Satellite Modems
PERFORMANCE SPECIFICATIONS
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW, typ.)
Harmonic Suppression (2nd, typ.)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance (max.)
Pushing
Pulling (14 dB Return Loss, Any Phase)
-120
MHz
-140
-160
1 kHz
VALUE
1210
-
1235
-111
-20
1-4.2
18
2.5鹵2.5
50
50
<0.4
<0.3
0 to 85
375
10 kHz
UNITS
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
100 kHz
鈩?/div>
pF
MHz/V
MHz
擄C
Operating Temperature Range
Package Style
POWER SUPPLY REQUIREMENTS
Supply Voltage (Vcc, nom.)
Supply Current (Icc, typ.)
5
20
APPLICATION NOTES
Vdc
mA
All specifications are typical unless otherwise noted and subject to change without notice.
鈥?/div>
AN-100/1 : Mounting and Grounding of VCOs
鈥?/div>
AN-102 : Proper Output Loading of VCOs
鈥?/div>
AN-107 : How to Solder Z-COMM VCOs
NOTES:
漏 Z-Communications, Inc.
Page 1
All rights reserved
1
2
