Controlled Baseline
One Assembly/Test Site
One Fabrication Site
Available in Military (鈥?5擄C/125擄C), Industrial
(鈥?0擄C/85擄C) Temperature Ranges
(1)
Extended Product Life Cycle
Extended Product-Change Notification
Product Traceability
Custom Temperature Ranges Available
1A
1Y
2A
2Y
3A
3Y
GND
1
2
3
4
5
6
7
14
13
12
11
10
9
8
V
CC
6A
6Y
5A
5Y
4A
4Y
DESCRIPTION/ORDERING INFORMATION
This hex buffer/driver is designed for 1.65-V to 5.5-V V
CC
operation.
The outputs of the SN74LVC07A device are open drain and can be connected to other open-drain outputs to
implement active-low wired-OR or active-high wired-AND functions. The maximum sink current is 24 mA.
Inputs can be driven from 1.8-V, 2.5-V, 3.3-V (LVTTL), or 5-V (CMOS) devices. This feature allows the use of
this device as a translator in a mixed-system environment.
ORDERING INFORMATION
T
A
鈥?0擄C to 85擄C
鈥?5擄C to 125擄C
(1)
TSSOP 鈥?PW
TSSOP 鈥?PW
PACKAGE
(1)
Reel of 2000
Reel of 2000
ORDERABLE PART NUMBER
SN74LVC07AIPWREP
SN74LVC07AMPWREP
TOP-SIDE MARKING
C07AEP
C07AMEP
Package drawings, standard packing quantities, thermal data, symbolization, and PCB design guidelines are available at
www.ti.com/sc/package.
FUNCTION TABLE
(each buffer/driver)
INPUT
A
H
L
OUTPUT
Y
H
L
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
UNLESS OTHERWISE NOTED this document contains
PRODUCTION DATA information current as of publication date.
Products conform to specifications per the terms of Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright 漏 2003鈥?008, Texas Instruments Incorporated
