Fiber Optics

XPAK

850 nm Module

10 Gigabit Pluggable Transceiver

Compatible with XPAK MSA Rev. 2.3

Preliminary Data Sheet

Features

Standards

鈥?Compatible with IEEE Std 802.3ae鈩?2002

鈥?Compatible with Fibre Channel 10GFC Draft 3.5

鈥?Compatible with XPAK MSA Rev. 2.3

Optical

V23833-G2005-A101

V23833-G6005-A101

V23833-G6005-A111

File: 2101

鈥?IEEE Ethernet: Serial 850 nm 10GBASE-SR

鈥?T11 Fibre Channel: Serial 850 nm 1200-M5-SN-I;

1200-M5E-SN-I; 1200-M6-SN-I

鈥?10 Gigabit Fibre Channel: 10.51875 Gbit/s

(V23833-G2005-A101)

鈥?10 Gigabit Ethernet: 10.3125 Gbit/s

(V23833-G6005-A1x1)

鈥?Transmission distance

鈥?up to 82 m

1)

(50 碌m MMF)

鈥?up to 300 m

1)

(on special MMF)

鈥?Vertical Cavity Surface Emitting Laser at 850 nm

(VCSEL)

鈥?LC connector, multimode fiber

鈥?Full duplex transmission mode

鈥?Eye safety class 1M (IEC 60825-1:A2)

File: 2117

1)

Maximum reach as defined by IEEE. Longer reach possible depending upon link implementation.

Part Number

Standard

De-Latch

Mechanism

Bail

None

1

Connector

LC

LC

LC

Laser Class

1M

1M

1M

2004-05-13

V23833-G2005-A101 Fibre Channel Bail

V23833-G6005-A101 Ethernet

V23833-G6005-A111 Ethernet

Preliminary Product Information
