P
R O D U C T
Small Form Factor (SFF) Transceiver
LC Connector
OC-3, OC-12, OC-48,
Single Mode 1310 nm, 3.3 V
Infineon's small form factor LC transceiver family is
designed for single mode fiber applications operating
at 1310 nm wavelength within synchronous optical
networks. The wide range of products covers data rates
from 100 Mb/s up to 2500 Mb/s by transmitting and
receiving light over distances up to 40 km. Its narrow
width design enables hardware designers to fit up to
32 modules on to a single line card. All units comply with
the latest SONET/SDH standards and meet FDA laser
class 1. They come in a fully shielded package to provide
best prevention against EMI radiation.
B
R I E F
SM SFF
Applications
Line cards for the backbone infrastruc-
ture of Internet and public switched
networks (SONET/SDH/ATM Networks)
s
High-speed server applications
s
Internet traffic management products
s
High speed router
s
Digital and optical cross connects
s
Add/drop multiplexer
s
Terminal multiplexer
s
Broadband/CATV
Features
s
Data rates from 100 Mb/s up to
2.5 Gb/s
s
1310 nm FP or DFB laser
s
3.3 V power supply
s
2by5 or 2by10 MSA compatible
footprint
s
LC connector
s
Half the size of current 1x9
SC transceiver
s
Full shielded for best EMI
performance
s
Tx and Rx monitoring functions
s
Distances up to 15 km
(40 km on OC-3) can be covered
Applied Standards
s
ITU-T G.957 STM
s
ATM Forum
s
Bellcore SONET/SDH
Documentation and Support Package
s
Data sheets
s
Cross reference
s
Samples
s
Qualification report
s
Test boards
Certifications
s
UL 94 V-0
s
FCC (Class B) and EN 55022
s
Class 1 FDA
s
IEC laser safety compliant
www.infineon.com/fiberoptics
SM SFF Transceiver
S O N E T / S D H / AT M
N e v e r
s t o p
t h i n k i n g .
