V23814-K1306-M230
Parallel Optical Link: PAROLI廬 Tx DC/MUX-ENC
V23815-K1306-M230
Parallel Optical Link: PAROLI廬 Rx DC/DEMUX-DEC
APPLICATIONS
Telecommunication
鈥?Switching equipment
鈥?Access network
Data Communication
鈥?Interframe (rack-to-rack)
鈥?Intraframe (board-to-board)
鈥?On board (optical backplane)
Absolute Maximum Ratings
Stress beyond the values stated below may cause permanent
damage to the device. Exposure to absolute maximum rating
conditions for extended periods of time may affect
device reliability.
Supply Voltage (V
CC
鈥揤
EE
).................................... 鈥?.3 V to 4.5 V
Data/Control Input Levels (V
IN
)
(1)
................ 鈥?.5 V to V
CC
+0.5 V
LVDS Input Differential Voltage (
|V
ID
|
)
(2)
.............................. 2.0 V
Operating Case Temperature (T
CASE
)
(3)
............... 0擄C to 80擄C
Storage Ambient Temperature (T
STG
)................ 鈥?0擄C to 100擄C
Operating Moisture ............................................... 20% to 85%
Storage Moisture.................................................... 20% to 85%
Soldering Conditions Temp/Time (T
SOLD,
t
SOLD
)
(4)
....260擄C/10s
ESD Resistance (all pins to V
EE
human body model)
(5)
....... 1 kV
Notes
1. At LVDS and LVCMOS inputs.
2. |V
ID
|=|(input voltage of non-inverted input minus input voltage of
inverted input)|.
3. Measured at case temperature reference point (see dimensional
drawing, Figure 13 on page 12).
4. Hot bar or hot air soldering.
5. To avoid electrostatic damage, handling cautions similar those used
for MOS devices must be observed.
FEATURES
鈥?Power supply (3.3 V)
鈥?Low voltage differential signal electrical interface (LVDS)
鈥?22 electrical data + 1 clock channels
鈥?Low skew, bit parallel transmission
鈥?Interface to SCI and HIPPI 6400 standard
鈥?12 optical data channels
鈥?Electrical transmission data rate of 150-500 Mbit/s per
channel, total link data rate up to 11 Gbit/s
鈥?Two clocking modes can be selected (SCI/Strobe)
鈥?Transmission distance up to 75 m at maximum data rate
鈥?850 nm VCSEL array technology
鈥?PIN diode array technology
鈥?62.5
碌m
graded index multimode fiber ribbon
鈥?MT based optical port
鈥?SMD technology
鈥?Class 1 FDA and Class 3A IEC laser safety compliant
鈥?FC open fiber interface supported (to configure a Class 1
IEC laser safety compliant system)
Fiber Optics
May 2000
