UTC UZ1084
LINEAR INTEGRATED CIRCUIT
5A ADJUSTABLE/FIXED LOW
DROPOUT LINEAR REGULATOR
DESCRIPTION
The UTC UZ1084-ADJ/Fixed voltage are low dropout
three-terminal regulators with 5A output current capability.
These devices have been optimized for low voltage
applications including V
TT
bus termination, where transient
response and minimum input voltage are critical.
On-chip thermal limiting provides protection against any
combination of overload and ambient temperature that would
create excessive junction temperatures.
1
2
3
12
3
TO-220
TO-263
FEATURE
*Fast transient response
*Low dropout Voltage at up to 5A
*Load regulation : 0.5% typical
*On-chip thermal limiting
1
23
TO-252
APPLICATIONS
*Desktop PCs, RISC and embedded processors鈥?supply
*GTI, SSTL logic Reference bus supply
*Low voltage VCC logic supply
*Battery-powered circuitry
*Post regulator for switching supply
*Cable and ADSL modems鈥?DSP core supply
*Set Top Boxes and Web Boxes modules鈥?supply
1: ADJ/GND
2: V
OUT
3: V
IN
TYPICAL APPLICATION CIRCUIT
Adjustable Voltage Regulator
UZ1084-ADJ
V
IN
=5V
+
10渭F
V
IN
ADJ
124
惟
+
V
OUT
V
OUT
=2.5V
at 5A
22渭F
124
惟
UTC
UNISONIC TECHNOLOGIES CO., LTD.
1
QW-R102-010,A
