UTC 8156
8 FUNCTIONS
XMAS LIGHT CONTROL
APPLICATION
*
Xmas light control ,any AC control toys.
FEATURES
* 8 functions
* Rotary switch select
* Built in PLL,50/60Hz auto detect.
CMOS
DIP-18
MODE FUNCTIONS
MODE
1
2
3
4
5
6
7
8
FUNCTIONS
AUTO SCAN SEC 2 TO SEC 7
IN WAVES
SEQUENTIAL
SLO-GOL
CHASING / FLASH
SLOW FADE
TWINKLE / FLASH
STEADY ON
ELECTRICAL CHARACTERISTICS
(@V
DD
=4V unless otherwise specified)
PARAMETER
Operating Voltage
Operating Current
BZ Driving Current
Oscillator Frequency
Operating Temperature
SYMBOL
V
DD
Iop
I
OH
Fosc
T
opr.
TEST CONDITIONS
No load
V
DS
=IV
鹵30%
TOL.
MIN.
TYP.
4
0.2
250
MAX.
5
2
UNIT
V
mA
mA
KHz
0
25
60
擄C
