USBLC6-2_08 Datasheet

  • USBLC6-2_08

  • Very low capacitance ESD protection

  • 14頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

USBLC6-2
Very low capacitance ESD protection
Features
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
2 data lines protection
Protects V
BUS
Very low capacitance: 3.5 pF max.
Very low leakage current: 150 nA max.
SOT-666 and SOT23-6L packages
RoHS compliant
SOT23-6L
USBLC6-2SC6
SOT-666
USBLC6-2P6
Benefits
鈻?/div>
鈻?/div>
鈻?/div>
Applications
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Very low capacitance between lines to GND for
optimized data integrity and speed
Low PCB space consumption: 2.9 mm
2
max for
SOT-666 and 9mm虜 max for SOT23-6L
Enhanced ESD protection. IEC 61000-4-2 level
4 compliance guaranteed at device level,
hence greater immunity at system level
ESD protection of V
BUS
High reliability offered by monolithic integration
Low leakage current for longer operation of
battery powered devices
Fast response time
Consistent D+ / D- signal balance:
鈥?Very low capacitance matching tolerance
I/O to GND = 0.015 pF
鈥?Compliant with USB 2.0 requirements
USB 2.0 ports up to 480 Mb/s (high speed)
Compatible with USB 1.1 low and full speed
Ethernet port: 10/100 Mb/s
SIM card protection
Video line protection
Portable electronics
Description
The
USBLC6-2SC6
and
USBLC6-2P6
are
monolithic application specific devices dedicated
to ESD protection of high speed interfaces, such
as USB 2.0, Ethernet links and video lines.
The very low line capacitance secures a high level
of signal integrity without compromising in
protecting sensitive chips against the most
stringent characterized ESD strikes.
Figure 1.
Functional diagram
I/O1
1
Complies with the following standards
鈻?/div>
IEC 61000-4-2 level 4:
鈥?15 kV (air discharge)
鈥?8 kV (contact discharge)
6
I/O1
GND
2
5
V
BUS
I/O2
3
4
I/O2
March 2008
Rev 3
1/14
www.st.com
14
