USAR SunAdapt

TM

UR6HCSUN

USAR SunAdapt

TM

IC Converts PS/2 Data to Sun

A Semtech Company

USAR Protocol Interpreter family

product specifications

Description

The USAR SunAdapt

TM

is a single

IC that converts any off-the-shelf or

proprietary PS/2 human input

device, such as a keyboard,

mouse, touch screen, barcode

scanner to a Sun-compatible

system.

This IC was designed for the

SunAdapt

TM

protocol interpreter

- a single box that emulates all the

functions of a PS/2 system

keyboard controller on one end

and provides output for a Sun-

compatible keyboard and mouse

on the other.

The IC allows an external PS/2

keyboard, an external PS/2 Mouse

and a Sun mouse to operate

concurrently. A Sun keyboard may

also operate with a PS/2 mouse

and Sun mouse as long as the

PS/2 keyboard has been

unplugged. The PS/2 devices may

be hot-plugged. No additional

software drivers or hardware,

including a power supply is

needed.

Features

鈥?Interfaces PS/2 data to Sun

鈥?Some devices can be used

concurrently

鈥?PS/2 devices can be hot-plugged

Applications

鈥?System Legacy Support

Pin Descriptions

鈥?Available in DIP, PLCC and Quad

Flat packages

鈥?Custom versions available in

small or large quantities

NU

VPP

_IRQ

_RESET

NC

NC

VCC

OSCI

OSCO

_KBRX

_KBRX1

NU

NU

NU

NU

NU

NU

NU

PS2MDAT

PS2MCLK

PS2KDAT

PS2KCLK

QFP

KBTX

IN4

IN3

IN2

IN1

_MSTX

_MSRX

DIP0

DIP1

DIP2

NU

Part Number: UR6HCSUN

(C) 1995-2000, USAR - A Semtech Company. All rights reserved.

6

NU

NU

NU

NU

NU

NU

PS2MDAT

PS2MCLK

PS2KDAT

PS2KCLK

NU

7

1

NU

NU

VPP

NC

_IRQ

_RESET

VCC

OSC1

OCSO

_KBRX

NU

40

39

12

NU

NU

NU

NU

NC

GND

BEEP

KBSEL

NU

NU

NC

PLCC

34

17

18

23

29

28

_KBRX1

KBTX

IN4

IN3

IN2

IN1

_MSTX

_MSRX

DIP0

DIP1

DIP2

USAR 鈥?A Semtech Company

Datasheet

DOC6-SUN-DS-101

NU

NU

NU

NU

GND

NU

BEEP

KBSEL

NU

NU

NU

1
