PRELIMINARY
UPVLED
ULTRA-VIOLET LED
P
RODUCT
P
REVIEW
KEY FEATURES
WWW .
Microsemi
.C
OM
Microsemi鈥檚 UPVLED product is a new LED which features an impressive
output of UV power. These products deliver superior thermals that keep junction
temperatures low with a remarkable package thermal resisitivity of 110 degrees
C/Watt. The Optomite package performs extremely well under extreme
temperature conditions with less wavelength shift and intensity degradation seen
by many competitors.
IMPORTANT:
For the most current data, consult
MICROSEMI鈥檚
website:
http://www.microsemi.com
Low Thermal Resistance
Rugged Optomite 0603 package
Single wire bond
High UV intensity
Directed beam angle
APPLICATIONS/BENEFITS
Adhesive curing applications
Various medical applications
Hydrocarbon leak detectors.
Aflatoxin (mold) detection.
Microcontamination (dust)
sensor.
Micron level surface defect
detector.
Authentication of coded
securities.
ABSOLUTE MAXIMUM RATINGS AT 25潞 C
(UNLESS OTHERWISE SPECIFIED)
Parameters
Forward Drive Current
Peak Forward Current
LED Operating Junction Temperature
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Electrostatic Discharge
ESD classification
THERMAL CHARACTERISTICS
(UNLESS OTHERWISE SPECIFIED)
Symbol
I
F
I
FP
Tj
V
R
P
D
T
OPR
T
S
ESD
Value
30
100
-40 to +150
8
100
-40 to +125
-45 to +130
1000
Class 2
Unit
DC
mA
mA
擄C
V
mW
擄C
擄C
V
Thermal Resistance
Junction-to Soldering Point
Symbol
R
胃JS
Value
110
Units
擄C/W
UPBLED-470B
UPBLED-470B
Operation of these UV devices require UV-blocking eyewear to guard against harmful radiation.
UVEX S1309CLSSX (LAB SAFETY SUPPLY, INC)
Copyright
錚?/div>
2002
Rev. 0.02, 2003-01-15
Microsemi
580 Pleasant Street, Watertown, MA. 02472-2408, 617-926-0404, Fax: 617-924-1235
Page 1
