UPD9930 Datasheet

  • UPD9930

  • LINEAR CODEC FOR DIGITAL CELLULAR TELEPHONE

  • 327.83KB

  • 78頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD9930
LINEAR CODEC FOR DIGITAL CELLULAR TELEPHONE
The
碌
PD9930 is a +3 V single power operation, low power consumption linear CODEC LSI developed for digital
cellular telephone use.
CODEC has a wide dynamic use.
This IC also features a microphone/receiver amplifier, a tone generator, DAI (Digital Audio Interface: conforming
to GSM11.10), and a power-saving function. These functions can be controlled by microcontroller.
In addition, 21 mW (TYP.) low power consumption is enabled during 3 V operation.
FEATURES
鈥?+3 V single power supply
鈥?Low power consumption
In operation: 7 mA (TYP.) (V
DD
= 3 V)
In stand-by mode: 50
碌
A (TYP.) (V
DD
= 3 V)
鈥?CODEC
鈥?13-bit precision linear coding
鈥?Transmission level can be controlled by microcontroller.
鈥?Analog input/output funciton
鈥?Low noise microphone amplifier
鈥?High output receiver amplifier
Piezo-electric receiver can be directly driven.
Gain canbe controlled by microcontroller.
鈥?On-chip amplifier for accessory input/output
鈥?Tone generator
鈥?Frequency, generating pattern and gain can be controlled
by microcontroller.
鈥?DTMF generation function
鈥?Various service tone generation function
鈥?GSM triple tone generation function
鈥?Desired tone frequency can be registered (0.3 to 3.4 kHz)
鈥?DAI
鈥?Conforming to GSM11.10
鈥?Test mode can be set by terminal or microcontroller
command.
鈥?Stand-by mode
鈥?Rise time at time of stand-by clearing: 30.5 ms (TYP.)
鈥?Master clock generation PLL (external clock input: 8 kHz)
鈥?Tone interrupt pattern output function
鈥?Ringer output function
ORDERING INFORMATION
Part Number
碌
PD9930G-22
Package
44-pin plastic QFP (10
脳
10 mm)
The information in this document is subject to change without notice.
Document No. S11616EJ2V0DS00 (2nd edition)
(Previous No. IC-3342)
Date Published November 1996 N
Printed in Japan
The mark
shows major revised points.
漏
1994,1996
