UPD78F9831GC-8EU Datasheet

  • UPD78F9831GC-8EU

  • 8-Bit Microcontroller

  • 48頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD78F9831
8-BIT SINGLE-CHIP MICROCONTROLLER
The
碌
PD78F9831 is an 8-bit single-chip microcontroller (for LCD driving) of the 78K/0S series.
The
碌
PD78F9831 is produced by replacing the internal ROM of the
碌
PD789830 with larger flash memory.
Flash memory can be written or erased electrically without having to remove it from board. Therefore, the
碌
PD78F9831 is best suited for prototypes in system development, low-volume production, or systems likely to be
upgraded frequently.
The functions of the
碌
PD78F9831 are described in the following user's manuals. Refer to these manuals
when designing a system based on the
碌
PD78F9831.
: U13679E
碌
PD789830 Subseries User's Manual
78K/0S Series User's Manual, Instruction : U11047E
FEATURES
鈥?/div>
Internal flash memory: 48 Kbytes
鈥?/div>
RAM sizes
鈥?/div>
Internal RAM : 2 Kbytes
鈥?/div>
LCD data RAM : 40
脳
16 bits
Variable minimum instruction execution time: From high-speed (0.4
碌
s: With the main system clock running at
5.0 MHz) to very low-speed (122
碌
s: With the subsystem clock running at 32.768 kHz)
38 I/O ports
Serial interface (UART00)
LCD controller/driver
鈥?/div>
Up to 40 segment signal outputs
鈥?/div>
Up to 16 common signal outputs
鈥?/div>
1/5 bias mode
Four timers:
鈥?/div>
16-bit timer
鈥?/div>
8-bit timer
鈥?/div>
Watch timer
鈥?/div>
Watchdog timer
Pulse output: Clock output/buzzer output
Built-in key return signal detection circuit
Power supply voltage: V
DD
= 2.7 to 5.5 V
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
APPLICATIONS
Card readers
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. U13477EJ1V0DS00 (1st edition)
Date Published May 2001 J CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1998
