DATA SHEET
碌
PD78081, 78082
8-BIT SINGLE-CHIP MICROCONTROLLER
MOS INTEGRATED CIRCUIT
DESCRIPTION
The
碌
PD78081, 78082 are members of the
碌
PD78083 subseries of the 78K/0 series microcontrollers.
Besides a high-speed, high-performance CPU, these microcontrollers have on-chip ROM, RAM, I/O ports, 8-bit
resolution A/D converter, timer, serial interface interrupt control, and other peripheral hardware.
The
碌
PD78P083 devices including a one-time PROM version and an EPROM version, both of which can operate
in the same power supply voltage range as a mask ROM version, and various development tools are available.
The details of the functions are described in the following user鈥檚 manuals. Be sure to read it before starting design.
碌
PD78083 Subseries User鈥檚 Manual
: IEU-1407
78K/0 Series User鈥檚 Manual 鈥?Instructions : IEU-1417
FEATURES
鈥?/div>
Internal ROM and RAM
Item
Part Number
Program Memory
Data Memory
Package
42-pin plastidc shrink DIP (600 mil)
44-pin plastic QFP (10
脳
10 mm)
(ROM)
8K bytes
16K bytes
(Internal High-speed RAM)
256 bytes
384 bytes
碌
PD78081
碌
PD78082
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Instruction execution time can be changed from high-speed (0.4
碌
s) to low-speed (12.8
碌
s)
I/O ports: 33
8-bit resolution A/D converter : 8 channels
Serial interface : 1 channel
3-wire serial I/O / UART mode : 1 channel
鈥?/div>
Timer : 3 channels
鈥?/div>
Supply voltage : V
DD
= 1.8 to 5.5 V
APPLICATION FIELDS
Air bags, CRT displays, keyboards, air conditioners, water heaters, boilers, fan heater, dash boards, etc.
The information in this document is subject to change without notice.
Document No. U11415EJ1V0DS00 (1st edition)
(Previous No. IP-3476)
Date Published July 1996 P
Printed in Japan
The mark
shows major revised points.
漏
1995
