UPD703201 Datasheet

  • UPD703201

  • 32-BIT SINGLE-CHIP MICROCONTROLLERS

  • 774.77KB

  • 98頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PRELIMINARY PRODUCT INFORMATION
碌
PD703201, 703201Y, 703204, 703204Y,
70F3201, 70F3201Y, 70F3204, 70F3204Y
V850ES/SA2
,
V850ES/SA3
32-BIT SINGLE-CHIP MICROCONTROLLERS
TM
TM
MOS INTEGRATED CIRCUIT
DESCRIPTION
The
碌
PD703201, 703201Y, 70F3201, and 70F3201Y (V850ES/SA2),
碌
PD703204, 703204Y, 70F3204, and
70F3204Y (V850ES/SA3) are products in the V850 Family
DMA controller.
In addition to their high real-time responsiveness and one-clock-pitch execution of instructions, the V850ES/SA2
and V850ES/SA3 include instructions suited to digital servo control applications such as multiplication instructions
executed via a hardware multiplier, saturation instructions, and bit manipulation instructions. As a real-time control
system, this device provides a high-level cost performance ideal for ultra-low-power DVC and portable audio
applications.
Detailed function descriptions are provided in the following user鈥檚 manuals. Be sure to read them before
designing.
V850ES/SA2, V850ES/SA3 User鈥檚 Manual Hardware:
To be prepared
V850ES User鈥檚 Manual Architecture:
To be prepared
TM
of 32-bit single-chip microcontrollers, and include
peripheral functions such as ROM/RAM, timer/counters, serial interfaces, an A/D converter, a D/A converter, and a
FEATURES
Number of instructions: 83
Minimum instruction execution time:
59 ns (@ 17 MHz operation with main system clock (f
XX
))
74 ns (@ 13.5 MHz operation with main system clock (f
XX
))
General-purpose registers: 32 bits
脳
32 registers
Instruction set:
Signed multiplication, saturation operations, 32-bit
shift instructions, bit manipulation instructions,
load/store instructions
Memory space:
64 MB linear address space
Memory block division function:
2 MB, 2 MB, 4 MB, 8 MB = Total four blocks
External bus interface: 16-bit data bus
Address bus: Separate output enabled
Internal memory
Mask ROM:
256 KB (
碌
PD703201, 703201Y,
703204, 703204Y)
Flash memory: 256 KB (
碌
PD70F3201, 70F3201Y,
70F3204, 70F3204Y)
RAM: 16 KB
The information contained in this document is being issued in advance of the production cycle for the
device. The parameters for the device may change before final production or NEC Corporation, at its own
discretion, may withdraw the device prior to its production.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. U15436EJ1V0PM00 (1st edition)
Date Published June 2001 N CP(K)
Printed in Japan
Interrupts and exceptions
Non-maskable interrupts: 2 sources
Maskable interrupts:
38 sources (
碌
PD703201, 70F3201)
39 sources (
碌
PD703201Y, 70F3201Y)
39 sources (
碌
PD703204, 70F3204)
40 sources (
碌
PD703204Y, 70F3204Y)
Software exceptions: 32 sources
Exception trap: 1 source
I/O lines Total: 82 (V850ES/SA2)
102 (V850ES/SA3)
Timer/counters
16-bit timer: 2 channels
8-bit timer: 4 channels
Real-time counter (for watch): 1 channel
Watchdog timer: 1 channel
漏
2001
