V850 family
Product Letter
Description
V853
32-bit RISC Microcontrollers
The single-chip V853 microcontroller is a member of NEC鈥檚 32-bit RISC V850 family.
It integrates CPU, ROM, RAM and peripheral functions on chip. The internal bus is 32 bits
wide, the external bus 16 bits wide. Controller memory options are listed in Table 1.
Applications
Like other V850 series controllers, the V853 device is used for real-time control
applications, such as servo motor control in computer peripherals and machine tools, for
engine management control, consumer electronics and multimedia. Flash memory, a variety
of serial communication channels and AD/DA converters make it the perfect choice for
compact communication terminals and complete control systems. Typical benefits of Flash
memory are individually programmed devices in the final production process and field
upgradability. With their low power consumption and power-saving modes, V853 devices
are also ideal for portable applications.
Features
鈥?Small 32-bit RISC CPU core
鈥?30 ns minimum instruction execution time
(33 MHz max. clock)
鈥?16-Mbyte linear address space
鈥?1-Mbyte external address space
鈥?32 general-purpose registers
鈥?74 instructions optimized for embedded
control
鈥?DSP functionality with 16-bit multiplication
and saturation logic in a single clock cycle
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Up to 8 Kbytes internal RAM
Interrupt controller
Real-time pulse unit/timers
Serial interface with baud rate generator
A/D and D/A converters
PWM
Clock generator
Power save functions
Mask ROM, Flash versions
100-pin LQFP package
Block Diagram
NMI
INTP
Interrupt
Controller
ROM
Mask
96/128
Kbytes
or Flash
128/256
Kbytes
CPU Core
PC
Instruction
Queue
ASTB
DSTB
Barrel Shifter
Hardware
Multiplier
16 x 16
> 32
R/W
Bus
Control
Unit
UBEN
LBEN
WAIT
A16-A19
AD0-AD15
HLDRQ
HLDAK
TI
TO
TCLR1
Timer/Counter
16-bit timer:
5 channels
System
Registers
SIO
SO0/TxD0
SI0/RxD0
SCK0
SO1/TxD1
SI1/RxD1
SCK1
SO2
SI2
SCK2
SO3
SI3
SCK3
UART/CSI
BRG
UART/CSI
BRG
CSI
BRG
CSI
AV
DD
AV
REF1
A/D Converter
PWM
PWM
AV
SS
ADTRG
ANI1-ANI7
RAM
4 Kbytes/
8 Kbytes
General
Registers
A
L
U
Internal Peripheral Bus
CKSEL
Oscillator and
Clock Generator
CLK
OUT
X1
X2
System Control
MODE
RESET
P0-11
ANO
Ports
D/A Converter
AV
REF
