DATA SHEET

MOS INTEGRATED CIRCUIT

碌

PD17P246

4-BIT SINGLE-CHIP MICROCONTROLLER

FOR SMALL GENERAL-PURPOSE INFRARED

REMOTE CONTROLLER

DESCRIPTION

The

碌

PD17P246 is a model of the

碌

PD17246 with a one-time PROM instead of an internal mask ROM.

Since the user can write programs to the

碌

PD17P246, it is ideal for experimental production or small-scale

production of the

碌

PD17240, 17241, 17242, 17243, 17244, 17245, or 17246 systems.

When reading this document, also read the documents related to the

碌

PD17240, 17241, 17242, 17243, 17244,

17245, and 17246.

Detailed function descriptions are provided in the following user鈥檚 manual. Be sure to read them

before designing.

碌

PD172脳脳 Subseries User's Manual: U12795E

FEATURES

鈥?Pin compatible with

碌

PD17240, 17241, 17242, 17243, 17244, 17245, and 17246 (except PROM programming

function)

鈥?Carrier generator for infrared remote controller (REM output)

鈥?17K architecture: General-purpose register method

鈥?Program memory (one-time PROM): 32 KB (16,384

脳

16)

鈥?Data memory (RAM): 447

脳

4 bits

RAM retention detector

鈥?Low-voltage detector

鈥?Supply voltage: V

DD

= 2.2 to 3.6 V (4

碌

s)

APPLICATIONS

Preset remote controllers, toys, and portable systems

ORDERING INFORMATION

Part Number

Package

30-pin plastic SSOP (7.62 mm (300))

碌

PD17P246M1MC-5A4

The information in this document is subject to change without notice. Before using this document, please

confirm that this is the latest version.

Not all products and/or types are available in every country. Please check with an NEC Electronics

sales representative for availability and additional information.

Document No. U15215EJ1V0DS00 (1st edition)

Date Published May 2003 N CP(K)

Printed in Japan

The mark

shows major revised points.
