DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD17704A, 17705A, 17707A, 17708A, 17709A
4-BIT SINGLE-CHIP MICROCONTROLLERS WITH DEDICATED
HARDWARE FOR DIGITAL TUNING SYSTEM
DESCRIPTION
The
碌
PD17704A, 17705A, 17707A, 17708A, and 17709A are 4-bit single-chip CMOS microcontrollers
containing hardware for digital tuning systems.
Provided with a wealth of hardware, these microcontrollers are available with many variations of ROM and
RAM capacities to support various applications.
Therefore, a high-performance, multi-function digital tuning system can be configured with only one chip.
In addition, a one-time PROM model,
碌
PD17P709A, which can be written only once and is ideal for program
evaluation and small-scale production of a
碌
PD17704A, 17705A, 17707A, 17708A, or 17709A system, is also
available.
FEATURES
碌
PD17704
Program memory (ROM)
16 KB
(8192
脳
16 bits)
General-purpose data
memory (RAM)
672
脳
4 bits
碌
PD17705
24 KB
(12288
脳
16 bits)
碌
PD17707
碌
PD17708
32 KB
(16384
脳
16 bits)
碌
PD17709
1120
脳
4 bits
1776
脳
4 bits
鈥?Instruction execution time
1.78
碌
s (with f
X
= 4.5 MHz crystal oscillator)
鈥?PLL frequency synthesizer
Dual modulus prescaler (130 MHz MAX.),
programmable divider, phase comparator, charge
pump
鈥?Abundant peripheral hardware units
General-purpose I/O ports, serial interfaces, A/D
converter, D/A converter (PWM output), BEEP
output, frequency counter
鈥?Many interrupts
External: 6 sources
Internal:
detector
鈥?Supply voltage: V
DD
= 5 V
鹵10%
6 sources
鈥?Power-on reset, CE reset, and power failure
Unless otherwise specified, the
碌
PD17709A is treated as the representative model in this document.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. U15722EJ1V1DS00 (1st edition)
Date Published October 2001 N CP (K)
Printed in Japan
The mark
shows major revised points.
漏
2001
