UPD17012GF-XXX-3BE Datasheet

  • UPD17012GF-XXX-3BE

  • MICROCONTROLLER|4-BIT|UPD17K CPU|CMOS|QFP|64PIN|PLASTIC

  • 310頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD17012
4-BIT SINGLE-CHIP MICROCONTROLLER WITH
DIGITAL TUNING SYSTEM HARDWARE
The
碌
PD17012 is a 4-bit single-chip CMOS microcontroller equipped with hardware for digital tuning systems.
The CPU employs 17K architecture and can directly manipulate the data memory, execute various operations,
and control the peripheral hardware with a single instruction. All the instructions are one-word 16-bit instructions.
Besides various I/O ports, an LCD controller/driver, A/D converter, D/A converter (PWM output), and BEEP output,
this microcontroller has a prescaler that can operate at up to 250 MHz, a PLL frequency synthesizer, and frequency
counter for digital tuning systems.
Consequently, a high-performance, multi-functional digital tuning system can be configured on a single chip.
In addition to the
碌
PD17012, a one-time PROM version for program evaluation and small-scale production, the
碌
PD17P012, is also available.
FEATURES
鈥?17K architecture: General-purpose register method
鈥?Program memory (ROM)
8 KB (4,096
脳
16 bits)
鈥?General-purpose data memory (RAM)
316
脳
4 bits
鈥?Instruction execution time
4.44
碌
s (with 4.5 MHz crystal resonator)
鈥?Decimal operation
鈥?Table reference
鈥?Hardware for PLL frequency synthesizer
Dual modulus prescaler (250 MHz max.), programmable
divider, phase comparator, charge pump
鈥?Various peripheral hardware
General-purpose I/O ports, LCD controller/driver, serial
interface, A/D converter, D/A converter (PWM output),
BEEP output, frequency counter
鈥?Interrupts
External: 1
Internal: 3
鈥?Power-on-reset, reset by CE pin, and power failure
detector
鈥?Power-saving CMOS
鈥?Supply voltage: V
DD
= 5 V鹵10%
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. U10101EJ3V0DS00 (3rd edition)
Date Published March 2000 N CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1994, 2000
