UPD16754 Datasheet

  • UPD16754

  • UPD16754 Data Sheet | Data Sheet[04/2003]

  • 19頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD16754
384-OUTPUT TFT-LCD SOURCE DRIVER
(COMPATIBLE WITH 256-GRAY SCALES)
DESCRIPTION
The
碌
PD16754 is a source driver for TFT-LCDs capable of dealing with displays with 256-gray scales. Data input
is based on digital input configured as 8 bits by 6 dots (2 pixels), which can realize a full-color display of 16,777,216
colors by output of 256 values
緯
-corrected by an internal D/A converter and 8-by-2 external power modules.
Because the output dynamic range is as large as V
DD2
鈭?/div>
0.2 V to V
SS2
+ 0.2 V, level inversion operation of the
LCD鈥檚 common electrode is rendered unnecessary. Also, to be able to deal with dot-line inversion, n-line inversion
and column line inversion when mounted on a single side, this source driver is equipped with a built-in 8-bit D/A
converter circuit whose odd output pins and even output pins respectively output gray scale voltages of differing
polarity. Assuring a clock frequency of 40 MHz when driving at 3.0 V, this driver is applicable to XGA-standard TFT-
LCD panels and SXGA TFT-LCD panels.
FEATURES
鈥?CMOS level input
鈥?384 Outputs
鈥?Input of 8 bits (gradation data) by 6 dots
鈥?Capable of outputting 256 values by means of 8-by-2 external power modules (16 units) and a D/A converter
鈥?Logic power supply voltage (V
DD1
): 3.0 to 3.6 V
鈥?Driver power supply voltage (V
DD2
): 8.5 to 9.5 V
鈥?Output dynamic range V
DD2
鈭?/div>
0.2 V to V
SS2
+ 0.2 V
鈥?High-speed data transfer: f
CLK
= 40 MHz MAX. (internal data transfer speed when operating at V
DD1
=
3.0 V)
鈥?Apply for dot-line inversion, n-line inversion and column line inversion
鈥?Output Voltage polarity inversion function (POL)
鈥?Display data inversion function (POL21, POL22)
ORDERING INFORMATION
Part Number
Package
TCP (TAB package)
碌
PD16754N -
脳脳脳
Remark
The TCP鈥檚 external shape is customized. To order the required shape, please contact one of our sales
representatives.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. S16434EJ1V0DS00 (1st edition)
Date Published April 2003 NS CP(K)
Printed in Japan
The mark
5
shows major revised points.
2001
