UPD16721 Datasheet

  • UPD16721

  • UPD16721 Data Sheet | Data Sheet[02/2002]

  • 193.55KB

  • 28頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD16721
384-OUTPUT TFT-LCD SOURCE DRIVER
(COMPATIBLE WITH 256-GRAY SCALES)
DESCRIPTION
The
碌
PD16721 is a source driver for TFT-LCDs capable of dealing with displays with 256-gray scales. Data input is
based on digital input configured as 8 bits by 6 dots (2 pixels), which can realize a full-color display of 16,777,216
colors by output of 256 values
緯
-corrected by an internal D/A converter and 8-by-2 external power modules.
Because the output dynamic range is as large as V
SS2
+ 0.2 V to V
DD2
鈥?0.2 V, level inversion operation of the LCD鈥檚
common electrode is rendered unnecessary. Also, to be able to deal with dot-line inversion, n-line inversion and
column line inversion when mounted on a single side, this source driver is equipped with a built-in 8-bit D/A converter
circuit whose odd output pins and even output pins respectively output gray scale voltages of differing polarity. The
maximum clock frequency is 70 MHz when driving at 3.0 V.
FEATURES
鈥?/div>
CMOS level input
鈥?/div>
384 outputs
鈥?/div>
Input of 8 bits (gray scale data) by 6 dots
鈥?/div>
Capable of outputting 256 values by means of 8-by-2 external power modules (16 units) and a D/A converter
鈥?/div>
Logic power supply voltage (V
DD1
): 2.5 to 3.4 V
鈥?/div>
Driver power supply voltage (V
DD2
): 13.0
鹵
0.5 V or 15.0
鹵
0.5 V (switchable, V
SEL
)
鈥?/div>
High-speed data transfer: f
CLK.
= 70 MHz MAX. (internal data transfer speed when operating at V
DD1
= 3.0 V)
= 55 MHz MAX. (internal data transfer speed when operating at V
DD1
= 2.5 V)
鈥?/div>
Output dynamic range: V
SS2
+ 0.2 V to V
DD2
鈥?0.2 V
鈥?/div>
Apply for dot-line inversion, n-line inversion and column line inversion
鈥?/div>
Output voltage polarity inversion function (POL)
鈥?/div>
Output inversion function (POL21/22)
鈥?/div>
Output reset control is possible (MODE)
鈥?/div>
Slew-rate control is possible (SRC)
鈥?/div>
Output resistance control is possible (ORC)
鈥?/div>
Single bank arrangement is possible (Loaded with slim TCP)
5
5
5
5
5
5
ORDERING INFORMATION
Part Number
Package
TCP (TAB package)
碌
PD16721N-xxx
Remark
The TCP鈥檚 external shape is customized. To order the required shape, so please contact one of our sales
representatives.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. S14791EJ1V0DS00 (1st edition)
Date Published February 2002 NS CP (K)
Printed in Japan
The mark
!
shows major revised points.
漏
2000
