PRELIMINARY PRODUCT INFORMATION
MOS INTEGRATED CIRCUIT
碌
PD161831
240/244-OUTPUT TFT-LCD SOURCE DRIVER WITH TIMING GENERATOR
(COMPATIBLE WITH 64-GRAY SCALES)
DESCRIPTION
The
碌
PD161831 is a source driver for LIPS TFTs with on-chip timing generator and featuring 240/244 outputs. Data
input as 6-bit x 3-dot digital data is output as 64
緯
-corrected values using an internal D/A converter, achieving
260,000-color (full-color) display.
FEATURES
鈥?/div>
CMOS level input
鈥?/div>
240/244 outputs (R, G, B output)
鈥?/div>
Input of 6 bits (gray-scale data) by 3 dots
鈥?/div>
Capable of outputting 64 values by means of 5 external power modules and a D/A converter
鈥?/div>
Output dynamic range: V
SS
+ 0.05 V to V
S
鈥?0.05 V
鈥?/div>
High-speed data transfer: f
CLK
= 20 MHz MAX. (during 2-times data transfer when operating at V
CC
= 2.5 V. During
1-time data transfer 10 MHz MAX.)
鈥?/div>
High-speed data transfer: f
CLK
= 16 MHz MAX. (during 2-times data transfer when operating at V
CC
= 2.2 V. During
1-time data transfer 8 MHz MAX.)
鈥?/div>
On-chip power supplies (driver power supply, gate top power supply, gate bottom power supply)
鈥?/div>
Logic power supply voltage (V
CC
): 2.2 to 3.6 V
鈥?/div>
DC/DC reference power supply (V
DC
): 2.5 to 3.6 V
鈥?/div>
On-chip timing generator (Outputs R, G, B switching signal to panel. Outputs gate control signal.)
鈥?/div>
On-chip 8-bit serial interface (applied to SPI)
ORDERING INFORMATION
Part Number
Package
Chip
碌
PD161831P
Remark
Purchasing the above chip entail the exchange of documents such as a separate memorandum or product
quality, so please contact one of our sales representatives.
The information contained in this document is being issued in advance of the production cycle for the
device. The parameters for the device may change before final production or NEC Corporation, at its own
discretion, may withdraw the device prior to its production.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. S16269EJ2V0PM00 (2nd edition)
Date Published October 2002 NS CP (K)
Printed in Japan
The mark
5
shows major revised points.
漏
2002
