UPC8186K-E1 Datasheet

  • UPC8186K-E1

  • RF MODULATOR|BIPOLAR|LLCC|24PIN|PLASTIC

  • 114.53KB

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
碌
PC8186K
DIRECT QUADRATURE MODULATOR IC FOR PDC SYSTEMS
DESCRIPTION
The
碌
PC8186K is a silicon microwave monolithic IC developed as quadrature modulator for PDC systems. This
IC integrates a pre-mixer for local signals plus a quadrature modulator operating from 893 MHz to 1 453 MHz. This
IC is packaged in 24-pin QFN and therefore is suitable for higher density mounting. This low power IC employs
NEC鈥檚 proprietary bipolar process NESAT
TM
III (f
T
= 20 GHz) and also has a built-in power save function and can
operate 2.7 to 3.6 V supply voltage.
Consequenty the
碌
PC8186K can contribute to make RF blocks smaller size, higher performance and lower power
consumption.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Directly modulate in 893 to 1 453 MHz
Built-in pre-mixer for local signals
External LC filter can be applied between modulator output and pre-mixer input terminal
Current consumption: I
CC
= 34 mA TYP. @V
CC
= 3.0 V
Equipped with power save function
24-pin QFN suitable for higher density mounting
APPLICATION
鈥?Digital cellular telephone: PDC800 MHz, PDC1.5 GHz
ORDERING INFORMATION
Part Number
Package
24-pin plastic QFN
(4.1
脳
5.2
脳
0.95 mm)
Embossed tape 12 mm wide.
Pin 1 is in pull-out direction.
QTY 2.5 kpcs/reel.
Supplying Form
碌
PC8186K-E1
Remark
To order evaluation samples, please contact your local NEC sales office. (Part number for sample order:
碌
PC8186K)
Caution
Electro-static sensitive devices
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. P14896EJ2V0DS00 (2nd edition)
Date Published October 2000 N CP(K)
Printed in Japan
漏
2000
