SILICON MMIC UPCONVERTER
UPC8125GR
WITH AGC + IQ MODULATOR
FEATURES
鈥?WIDE SUPPLY VOLTAGE RANGE:
2.7 to 5.5 V
鈥?OUTPUT FREQUENCY RANGE:
1.8 to 2.0 GHz
鈥?INTERNAL LPF TO REJECT LO & SPURIOUS
LEAKAGE
鈥?PORTS FOR EXTERNAL IF FILTER
鈥?AGC FUNCTION: 40 dB RANGE
鈥?POWER SAVE FUNCTION
鈥?SMALL 20 PIN SSOP PACKAGE
鈥?TAPE AND REEL PACKAGING AVAILABLE
Vcc (MOD)
Filter 1
Filter 2
I
Ib
Q
Qb
Lo1 in
Lo1 inb
INTERNAL BLOCK DIAGRAM
1
2
3
4
5
6
7
8
x2
9
GND
10
LPF LPF
90 deg. Phase
Shifter (梅 2)
(Top View)
Reg.
Reg.
20
Vcc (Up-con)
19
RFout
18
GND
17
GND
16
Vps
15
VAGC
14
GND
13
Lo2 in
12
Lo2 inb
11
GND
DESCRIPTION
The UPC8125GR is a Silicon MMIC manufactured with the
NESAT III
TM
silicon bipolar process. The IC consists of a 1.8 -
2.0 GHz upconverter with AGC function and a 220 - 270 MHz IQ
modulator. The device operates over a wide 2.7 - 5.5 V supply
voltage range and features a power save function. The device
was specifically designed for digital mobile communication
applications such as 1900 MHz PCS and PHS handsets.
NEC's stringent quality assurance and test procedures ensure
the highest reliability and performance.
ELECTRICAL CHARACTERISTICS
(T
A
= 25擄C, V
CC
= 3.0 V, unless otherwise specified)
PART NUMBER
PACKAGE OUTLINE
SYMBOLS
I
CC
UP CONVERTER + QUADRATURE MODULATOR TOTAL
I
CC(PS)
P
RFout 1
P
RFout 2
LOL
ImR
IM
3 I/Q
GCR
T
PS(RISE)
T
PS (FALL)
Z
I/Q
I
I/Q
Z
LO
1
EVM
Padj
PARAMETERS AND CONDITIONS
Total Circuit Current (no input signal)
Total Circuit Current at Sleep Mode
Total Output Power 1
Total Output Power 2
Lo Carrier Leak
Image Rejection (Side Band leak)
I/Q 3rd Order Intermodulation Distortion
2
AGC Amp. Gain control range
Power Save Rise Time
Power Save Fall Time
Input Impedance I and Q Ports
2
I/Q Bias Current
Lo1 Input VSWR
Error Vector Magnitude
Adjacent Channel Power
V
AGC
= 3 V to 0.5 V
V
PS (OFF)
鈫?/div>
V
PS (ON)
V
PS (ON)
鈫?/div>
V
PS (OFF)
f
I/Q
= 24 KH
Z
,I
鈫?/div>
Ib,Q
鈫?/div>
Qb
I
鈫?/div>
Ib,Q
鈫?/div>
Qb
f
LO
1= 220 MHz to 270 MHz
MOD Pattern : PN9
鈭唂
= 600 KH
Z
MOD Pattern : PN9
%rms
dBc
V
PS
鈮?/div>
0.5 V (Low)
V
AGC
= 3.0 V
V
AGC
= 0.5 V
f
LO
1 + f
LO
2
UNITS
mA
碌A(chǔ)
dBm
dBm
dBc
dBc
dBc
dB
碌S
碌S
k鈩?/div>
碌A(chǔ)
25
MIN
UPC8125GR
S20 (SSOP 20)
TYP
36
0.3
-10
-50
-37
-35
-50
40
2
2
200
5
1.2:1
2.5
-68
5
5
-30
-30
-30
10
MAX
Notes:
1. P
IFIN
= -20 dBm
2. V
I/Q
= 1.5 V (DC) +0.5 Vp-p (AC)
California Eastern Laboratories
