DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
碌
PC8126GR
900 MHz BAND DIRECT QUADRATURE MODULATOR IC
FOR DIGITAL MOBILE COMMUNICATION
DESCRIPTION
The
碌
PC8126GR is a silicon monilithic integrated circuit designed as 900 MHz band direct guadrature modulator
for digital mobile communication systems. This Si-MMIC consists of pre-mixer for RF and IF local oscillator and 900
MHz band guadrature modulator which are packaged in 20 pin SSOP. The device has power save function and can
operate 2.7 V to 3.6 V supply voltage. Therefore, it can contribute to make RF block small, high performance and low
power consumption.
FEATURES
鈥?Direct modulation range : 915 MHz to 960 MHz
鈥?Pre-mixer for RF and IF local oscillator is incorporated.
鈥?External local filter can be applied between pre-mixer output and modulator input port.
鈥?Low operation current
: I
CC
= 35 mA (typ.) @V
CC
= 3 V
鈥?Equipped with power save function.
鈥?20 pin SSOP suitable for high density surface mounting.
APPLICATIONS
鈥?Digital cellular phones (PDC900 MHz etc.)
ORDERING INFORMATION
PART NUMBER
PACKAGE
20 pin plastic SSOP (225 mil)
SUPPLYING FORM
Embossed tape, 12 mm wide.
Pins 1 through 10 are in tape pull-
out direction.
QUANTITY
2500 pcs/Reel
碌
PC8126GR-E1
To order evaluation samples, please contact your local NEC sales office.
(Part number for sample order:
碌
PC8126GR, Quantity: 20 pcs/Unit)
Caution electro-static sensitive devices.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. P11487EJ2V0DS00 (2nd edition)
Date Published October 1999 N CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1997, 1999
