DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
碌
PC8112TB
SILICON MMIC 1st FREQUENCY DOWN-CONVERTER
FOR CELLULAR/CORDLESS TELEPHONE
DESCRIPTION
The
碌
PC8112TB is a silicon monolithic integrated circuit designed as 1st frequency down-converter for
cellular/cordless telephone receiver stage. This IC consists of mixer and local amplifier. The
碌
PC8112TB features
high impedance output of open collector. Similar ICs of the
碌
PC2757TB and
碌
PC2758TB feature low impedance
output of emitter follower. These TB suffix ICs which are smaller package than conventional T suffix ICs contribute to
reduce your system size.
The
碌
PC8112TB is manufactured using NEC鈥檚 20 GHz f
T
NESAT鈩II silicon bipolar process. This process uses
silicon nitride passivation film and gold electrodes. These materials can protect chip surface from external pollution
and prevent corrosion/migration. Thus, this IC has excellent performance, uniformity and reliability.
FEATURES
鈥?Excellent RF performance
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
: IIP
3
= 鈥? dBm@f
RFin
= 1.9 GHz (reference)
IM
3
= 鈥?8 dBc@P
RFin
= 鈥?8 dBm, 1.9 GHz (reference)
Similar conversion gain to
碌
PC2757 and lower noise figure than
碌
PC2758
Minimized carrier leakage
: RF
Io
= 鈥?0 dB@f
RFin
= 900 MHz (reference)
RF
Io
= 鈥?5 dB@f
RFin
= 1.9 GHz (reference)
High linearity
: P
O (sat)
= 鈥?.5 dBm TYP.@f
RFin
= 900 MHz
P
O (sat)
= 鈥? dBm TYP.@f
RFin
= 1.9 GHz
Low current consumption
: I
CC
= 8.5 mA TYP.
Supply voltage
: V
CC
= 2.7 to 3.3 V
High-density surface mounting : 6-pin super minimold package
APPLICATIONS
鈥?1.5 GHz to 1.9 GHz cellular/cordless telephone (PHS, DECT, PDC1.5G and so on)
鈥?800 MHz to 900 MHz cellular telephone (PDC800M and so on)
ORDER INFORMATION
Part Number
Package
6-pin super minimold
Markings
C2K
Supplying Form
Embossed tape 8 mm wide.
Pin 1, 2, 3 face the tape perforation side.
Qty 3kpcs/reel.
碌
PC8112TB-E3
Remark
To order evaluation samples, please contact your local NEC sales office.
(Part number for sample order:
碌
PC8112TB)
Caution Electro-static sensitive devices
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. P12808EJ2V0DS00 (2nd edition)
Date Published June 2000 N CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1997, 2000
