DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
碌
PC24A00 Series
THREE TERMINAL LOW DROPOUT VOLTAGE REGULATOR
DESCRIPTION
The
碌
PC24A00 series is a low dropout voltage three terminal regulator that has realized a minimum voltage
differential between the I/O of no more than 1 V when the output current is 2 A through the employment of a PNP
transistor at the output stage.
Due to its ability to achieve a greater reduction in the power loss compared with conventional three-terminal
regulators, the
碌
PC24A00 series is ideal for use as the secondary side smoothing circuit of a power supply.
FEATURES
鈥?/div>
Output current in excess of 2 A
鈥?/div>
High accuracy output voltage:
鈭?/div>
V
O
=
鹵2%
MAX. (T
J
= 25擄C, I
O
= 1 A)
鈥?/div>
Low dropout voltage: V
DIF
= 1 V MAX. (I
O
= 2 A)
鈥?/div>
On-chip thermal shut down circuit, over-current protection circuit and safe operating area protection circuit
ORDERING INFORMATION
Part Number
Package
3-pin plastic SIP (MP-45G) (Isolated TO-220)
3-pin plastic SIP (MP-45G) (Isolated TO-220)
3-pin plastic SIP (MP-45G) (Isolated TO-220)
Output Voltage
5V
12 V
15 V
碌
PC24A05HF
碌
PC24A12HF
碌
PC24A15HF
PIN CONFIGURATION (Marking Side)
3-pin plastic SIP (MP-45G)
碌
PC24A05HF, 24A12HF, 24A15HF
1
2
3
1: INPUT
2: GND
3: OUTPUT
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. G14632EJ4V0DS00 (4th edition)
Date Published March 2003 NS CP(K)
Printed in Japan
The mark
5
shows major revised points.
