UPC2260 Datasheet

  • UPC2260

  • UPC2260 Data Sheet | Data Sheet[06/2000]

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
碌
PC2260
LOW DROPOUT VOLTAGE REGULATOR WITH SYSTEM RESET PIN
DESCRIPTION
The
碌
PC2260 is a 500 mA maximum output current low dropout voltage regulator with a reset pin that outputs a reset
signal when a drop in the output voltage is detected, and a reset signal output timing adjustment pin.
The output voltage is 5 V, and the minimum voltage difference between input and output is extremely low, making this
product ideal for use in the power supply circuits of systems with built-in battery-driven microprocessors.
Because the reverse leakage current of this power supply is about 10
碌
A even if a voltage is applied to the output pin
when the input voltage is cut off, a reverse protection diode is not necessary even in systems requiring battery backup.
FEATURES
鈥?Outputs reset signal (active low) when the output voltage drops.
鈥?Power on reset constant can be set by attaching a single capacitor.
鈥?Low minimum voltage difference between input and output
V
DIF
= 0.5 V TYP (when I
O
= 500 mA)
.
鈥?Low reverse current leakage during back up
I
OLK
= 10
碌
A MAX. (at V
IN
= 0 V, V
O
= 5 V, 0擄C
鈮?/div>
T
J
鈮?/div>
125擄C)
PIN CONFIGURATION (Marking Side)
5-pin plastic V-DIP (V)
碌
PC2260V
1: INPUT
2: RESET
1 2 3 4 5
3: GND
4: DELAY CAPACITOR
5: OUTPUT
ORDERING INFORMATION
Part Number
Package
5-pin plastic V-DIP (V)
碌
PC2260V
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. G14901EJ2V0DS00 (2nd edition)
Date Published June 2000 NS CP (K)
Printed in Japan
漏
2000
