DATA SHEET

NPN SILICON RF TWIN TRANSISTOR

碌

PA844TC

NPN SILICON RF TRANSISTOR (WITH 2 DIFFERENT ELEMENTS)

IN A FLAT-LEAD 6-PIN THIN-TYPE ULTRA SUPER MINIMOLD

FEATURES

鈥?Ideal for 3.6 to 4.2 GHz oscillation application

鈥?2 different built-in transistors (2SC5436, 2SC5668)

Q1: 9.0 GHz f

high-gain transistor

= 9.0 GHz TYP.,

錚

21e

錚?/div>

= 7.5 dB TYP. @ V

= 1 V, I

= 10 mA, f = 2 GHz

Q2: 21.0 GHz f

high-gain transistor

= 21.0 GHz TYP.,

錚

21e

錚?/div>

= 11.5 dB TYP. @ V

= 2 V, I

= 20 mA, f = 2 GHz

鈥?Flat-lead 6-pin thin-type ultra super minimold package

BUILT-IN TRANSISTORS

3-pin thin-type ultra super minimold part No.

2SC5436

2SC5668

ORDERING INFORMATION

Part Number

Quantity

50 pcs (Non reel)

3 kpcs/reel

Supplying Form

鈥?8 mm wide embossed taping

鈥?Pin 6 (Q1 Base), Pin 5 (Q2 Emitter), Pin 4 (Q2 Base)

face the perforation side of the tape

碌

PA844TC

碌

PA844TC-T1

Remark

To order evaluation samples, contact your nearby sales office.

The unit sample quantity is 50 pcs.

Because this product uses high-frequency technology, avoid excessive static electricity, etc.

The information in this document is subject to change without notice. Before using this document, please confirm that

this is the latest version.

Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices

representative for availability and additional information.

Document No. PU10012EJ01V0DS (1st edition)

(Previous No. P15280EJ1V0DS00)

Date Published November 2001 CP(K)

Printed in Japan

The mark

鈥?/div>

shows major revised points.

漏

NEC Corporation 2001

漏

NEC Compound Semiconductor Devices 2001
