PRELIMINARY DATA SHEET
SILICON TRANSISTOR
碌
PA814T
MICROWAVE LOW NOISE AMPLIFIER
NPN SILICON EPITAXIAL TRANSISTOR
(WITH BUILT-IN 2
脳
2SC5193) SMALL MINI MOLD
FEATURES
鈥?Low Voltage Operation, Low Phase Distortion
鈥?Low Noise
NF = 1.5 dB TYP. @V
CE
= 3 V, I
C
= 7 mA, f = 2 GHz
NF = 1.7 dB TYP. @V
CE
= 1 V, I
C
= 3 mA, f = 2 GHz
鈥?Large Absolute Maximum Collector Current
I
C
= 100 mA
鈥?A Small Mini Mold Package Adopted
鈥?Built-in 2 Transistors (2
脳
2SC5193)
PACKAGE DRAWINGS
(Unit: mm)
2.1 鹵0.1
1.25 鹵0.1
0.65 0.65
2.0 鹵0.2
1.3
2
3
ORDERING INFORMATION
0.9 鹵0.1
PART NUMBER
QUANTITY
Loose products
(50 PCS)
PACKING STYLE
Embossed tape 8 mm wide. Pin 6 (Q1
Base), Pin 5 (Q1 Emitter), Pin 4 (Q2 Emitter)
face to perforation side of the tape.
0.7
碌
PA814T
4
5
碌
PA814T-T1
Taping products
(3 KPCS/Reel)
Remark
If you require an evaluation sample, please contact an NEC Sales
Representative. (Unit sample quantity is 50 pcs.)
PIN CONFIGURATION (Top View)
ABSOLUTE MAXIMUM RATINGS (T
A
= 25
擄
C)
PARAMETER
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current
Total Power Dissipation
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
P
T
RATING
9
6
2
100
150 in 1 element
200 in 2 elements
Note
150
鈥?5 to +150
UNIT
V
6
Q1
5
0 to 0.1
4
Q2
V
V
mA
mW
1
2
3
Junction Temperature
Storage Temperature
T
j
T
stg
藲C
藲C
PIN CONNECTIONS
1. Collector (Q1)
4. Emitter (Q2)
2. Base (Q2)
5. Emitter (Q1)
3. Collector (Q2)
6. Base (Q1)
Note
110 mW must not be exceeded in 1 element.
This device uses radio frequency technology. Take due precautions to protect it from excessive input levels such as static electricity.
The information in this document is subject to change without notice.
Document No. P11467EJ1V0DS00 (1st edition)
Date Published June 1996 P
Printed in Japan
