鈥?/div>
Simplifies Circuit Design
Reduces Board Space
Reduces Component Count
Available in 8 mm, 7 inch/3000 Unit Tape and Reel.
SC鈥?8A/SOT鈥?23
CASE 419A
STYLE 6
MARKING
DIAGRAM
5
Ux
1
2
3
4
MAXIMUM RATINGS
(T
A
= 25擄C unless otherwise noted, common for Q
1
and Q
2
, 鈥?minus sign for Q
1
(PNP) omitted)
Rating
Collector-Base Voltage
Collector-Emitter Voltage
Collector Current
Symbol
V
CBO
V
CEO
I
C
Value
50
50
100
Unit
Vdc
Vdc
mAdc
Ux = Device Marking
x = 2, 3 or 5
THERMAL CHARACTERISTICS
Thermal Resistance 鈥?Junction-to-Ambient
(surface mounted)
Operating and Storage Temperature
Range
Total Package Dissipation
@ T
A
= 25擄C (Note 1.)
R
胃JA
T
J
, T
stg
P
D
833
鈥?5 to
+150
*150
擄C/W
擄C
mW
ORDERING INFORMATION
Device
UMC2NT1
UMC3NT1
UMC5NT1
Package
SOT鈥?23
SOT鈥?23
SOT鈥?23
Shipping
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
DEVICE MARKING AND RESISTOR VALUES
Transistor 1 鈥?PNP
Device
UMC2NT1
UMC3NT1
UMC5NT1
Marking
U2
U3
U5
R1 (K)
22
10
4.7
R2 (K)
22
10
10
Transistor 2 鈥?NPN
R1 (K)
22
10
47
R2 (K)
22
10
47
Preferred
devices are recommended choices for future use
and best overall value.
1. Device mounted on a FR-4 glass epoxy printed circuit board using the
minimum recommended footprint.
漏
Semiconductor Components Industries, LLC, 2001
1
April, 2001 鈥?Rev. 1
Publication Order Number:
UMC2NT1/D
