UFB60FA20 Datasheet

  • UFB60FA20

  • 200V 60A Ultrafast Doubler Diode in a SOT-227 package

  • 213.60KB

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Bulletin PD-20778 03/02
UFB60FA20
Insulated Ultrafast Rectifier Module
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Two Fully Independent Diodes
Ceramic Fully Insulated Package (V
ISOL
= 2500V AC)
Ultrafast Reverse Recovery
Ultrasoft Reverse Recovery Current Shape
Low Forward Voltage
Optimized for Power Conversion: Welding and Industrial SMPS Applications
Industry Standard Outline
Plug-in Compatible with other SOT-227 Packages
Easy to Assemble
Direct Mounting to Heatsink
t
rr
= 27ns
I
F(AV)
= 60A
@ T
C
= 100擄C
V
R
= 200V
Description
The UFB60FA20 insulated modules integrate two state-of-the-art International Rectifier's Ultrafast recovery rectifiers
in the compact, industry standard SOT-227 package. The planar structure of the diodes, and the platinum doping life-
time control, provide a Ultrasoft recovery current shape, together with the best overall performance, ruggedness and
reliability characteristics.
These devices are thus intended for high frequency applications in which the switching energy is designed not to be
predominant portion of the total energy, such as in the output rectification stage of Welding machines, SMPS, DC-
DC converters. Their extremely optimized stored charge and low recovery current reduce both over dissipation in the
switching elements (and snubbers) and EMI/ RFI.
Absolute Maximum Ratings
Parameters
V
R
I
F
I
FSM
P
D
V
ISOL
T
J
, T
STG
Cathode-to-Anode Voltage
Continuous Forward Current, T
C
= 100擄C
Single Pulse Forward Current, T
C
= 25擄C
Max. Power Dissipation, T
C
= 100擄C
Operating Junction and Storage Temperatures
Per Diode
Per Diode
Per Module
Max
200
30
250
53
2500
- 55 to 150
Units
V
A
W
V
擄C
RMS Isolation Voltage, Any Terminal to Case, t = 1 min
Case Styles
UFB60FA20
1
4
SOT-227
www.irf.com
2
3
1
