BiMOS II 10-BIT SERIAL-INPUT, LATCHED
SOURCE DRIVERS FOR -40
擄
C TO +85
擄
C OPERATION
The UCQ5810AF, UCQ5810EPF, and UCQ5810LWF combine a 10-bit
CMOS shift register and accompanying data latches, control circuitry, bipolar
sourcing outputs with DMOS active pull-downs. Designed primarily to drive
vacuum-fluorescent displays, the 60 V and -40 mA output ratings also allow
these devices to be used in many other peripheral power driver applications.
The UCQ5810AF/EPF/LWF feature reduced supply requirements (active
DMOS pull-downs) and lower saturation voltages when compared with the
original UCQ5810A.
The CMOS shift register and latches allow direct interfacing with
microprocessor-based systems. With a 5 V supply, they will operate to at
least 3.3 MHz. At 12 V, higher speeds are possible. Use with TTL may
require appropriate pull-up resistors to ensure an input logic high.
ABSOLUTE MAXIMUM RATINGS
at T
A
= 25擄C
Logic Supply Voltage, V
DD
.....................
15 V
Driver Supply Voltage, V
BB
....................
60 V
Continuous Output Current Range,
I
OUT
..........................
-40 mA to +15 mA
Input Voltage Range,
V
IN
........................
-0.3 V to V
DD
+ 0.3 V
Package Power Dissipation, P
D
(UCQ5810AF) ...........................
2.08 W*
(UCQ5810EPF) ........................
1.60 W*
(UCQ5810LWF) ........................
1.33 W*
Operating Temperature Range,
T
A
..................................
-40
擄
C to +85
擄
C
Storage Temperature Range,
T
S
................................
-55
擄
C to +150
擄
C
*Derate linearly to 0 W at +150擄C.
Caution: CMOS devices have input static
protection but are susceptible to damage when
exposed to extremely high static electrical
charges.
Note that the UCQ5810AF (dual in-line package)
and UCQ5810LWF (small-outline IC package)
are electrically identical and share a common
terminal number assignment.
n
e
W
em
E
c
N
la
R
rep
O
d
F
de
T
n
O
me
N
m
o
c
e
R
Dwg. PP-029
A CMOS serial data output enables cascade connections in applications
requiring additional drive lines. Similar devices are available as the
UCQ5811A (12 bits), UCQ5812AF/EPF (20 bits), and UCQ5818AF/EPF (32
bits).
The UCQ5810AF/EPF/LWF output source drivers are npn Darlingtons
capable of sourcing up to 40 mA. The DMOS active pull-downs are capable
of sinking up to 15 mA. For inter-digit blanking, all of the output drivers can
be disabled and the DMOS sink drivers turned on by the BLANKING input
high.
The UCQ5810AF is furnished in an 18-pin dual in-line plastic package.
The UCQ5810EPF is furnished in a 20-lead plastic chip carrier. The
UCQ5810LWF is furnished in a wide-body, small-outline plastic package
(SOIC) with gull-wing leads. Copper lead frames, reduced supply current
requirements, and lower output saturation voltages allow all devices to source
25 mA from all outputs continuously, over the entire operating temperature
range.
