UCC5670
SLVS394A 鈥?MAY 2002
9 LINE MULTIMODE SCSI TERMINATOR
WITH SPI 3 MODE DELAY, DISCONNECT, AND STATUS LINES
FEATURES
D
Auto Selection Single Ended (SE) or Low
D
D
D
D
D
Voltage Differential (LVD) Termination
Meets SCSI-1, SCSI-2, SCSI-3 SPI, Ultra
(Fast-20), Ultra2 (SPI-2 LVD), Ultra3/Ultra160
(SPI-3) and Ultra320 (SPI-4) Standards
2.7-V to 5.25-V TERMPWR Operation
Differential Fail-Safe Bias
Pin Compatible With UCC5630A With Digital
SPI-3 Mode Change/Filter Delay
Thermal Packaging for Low Junction
Temperature and Better MTBF
DESCRIPTION
The UCC5670 SCSI multimode terminator, comprises
both single-ended (SE) and low-voltage differential
(LVD) termination and is intended to bridge the
transition from single ended to LVD SCSI parallel
interface (SPI-2), (SPI-3), and (SPI-4). The low voltage
differential signaling configuration is required to meet
the higher SCSI speeds and smaller skew budgets. LVD
is specified for Ultra2, (Fast-40), Ultra3/Ultra160
(Fast-80), Ultra320 (Fast-160) and meets the
requirements for speeds up to Fast-320. The UCC5670
can not be used with High Power Differential
(HIPD)鈥?EIA485) devices. When it detects high power
differential devices, the terminator lines switch to a high
impedance state.
The UCC5670 is offered in a 36-pin MWP package.
AVAILABLE OPTIONS
TA
0擄C to 70擄C
Disconnect
Status
Stat s
Regular
Packaged
Device
MWP
UCC5670MWP
鈥?The MWP package is available taped and reeled. Add R suffix to device
type (e.g. UCC5670MWPR) to order quantities of 1000 devices per reel.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
Copyright
錚?/div>
2002, Texas Instruments Incorporated
www.ti.com
1
