UC29432 Datasheet

  • UC29432

  • Precision Analog Controller

  • 5頁

  • TI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Precision Analog Controller
FEATURES
鈥?/div>
Programmable Transconductance for
Optimum Current Drive
鈥?/div>
Accessible 1.3V Precision Reference
鈥?/div>
Both Error Amplifier Inputs Available
鈥?/div>
0.7% Overall Reference Tolerance
鈥?/div>
0.4% Initial Accuracy
鈥?/div>
2.2V to 36.0V Operating Supply
Voltage and User Programmable
Reference
鈥?/div>
Reference Accuracy Maintained for
Entire Range of Supply Voltage
鈥?/div>
Superior Accuracy and Easier
Compensation for Optoisolator
Application
鈥?/div>
Low Quiescent Current (0.50mA Typ)
UC19432
UC29432
UC39432
UC39432B
DESCRIPTION
The UC39432 is an adjustable precision analog controller with 100mA sink
capability if the ISET pin is grounded. A resistor between ISET and ground
will modify the transconductance while decreasing the maximum current
sink. This will add further control in the optocoupler configuration. The
trimmed precision reference along with the non-inverting error amplifier in-
puts are accessible for custom configuration. A sister device, the UC39431
adjustable shunt regulator, has an on-board resistor network providing six
preprogrammed voltage levels, as well as external programming capability.
BLOCK DIAGRAM
UDG-95093
03/99
