UC2886 Datasheet

  • UC2886

  • Average Current Mode PWM Controller IC

  • 199.50KB

  • 9頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

application
INFO
available
UC2886
UC3886
Average Current Mode PWM Controller IC
FEATURES
鈥?/div>
10.3V - 20V Operating Range
鈥?/div>
Low Offset Voltage Amplifier
鈥?/div>
High Bandwidth Current and Voltage
Amplifiers
鈥?/div>
Low Offset Current Sense
鈥?/div>
Undervoltage Lockout
鈥?/div>
Trimmed 5 Volt Reference
鈥?/div>
Externally Programmable Oscillator
Charge Current
鈥?/div>
1.5A Peak Totem Pole Output
鈥?/div>
Available in 16-pin DIL or SOIC
Packages
Amplifier
DESCRIPTION
The UC3886 family of PWM controller ICs is designed for DC-to-DC con-
verters with average current mode control. It is designed for use in con-
junction with the UC3910 4-bit DAC and Voltage Monitor. The UC3886
drives an external N-channel MOSFET and can be used to power the In-
tel Pentium廬 Pro and other high-end microprocessors.
The UC3886 in conjunction with the UC3910 converts 5VDC to an adjust-
able output ranging from 2.0V to 3.5V in 100mV steps with 35mV DC sys-
tem accuracy.
The oscillator is programmed by the user鈥檚 selection of an external resis-
tor and capacitor, and is designed for 300kHz typical operation.
The voltage and current amplifiers have 3.5MHz gain-bandwidth product
to satisfy high performance system requirements.
The internal current sense amplifier permits the use of a low value current
sense resistor, minimizing power loss. It has inputs and outputs accessi-
ble to allow user-selection of gain-setting resistors, and is internally com-
pensated for a gain of 5 and above. The command voltage input is
buffered and provided for use as the reference for the current sense am-
plifier.
The output of the voltage amplifier (input to the current amplifier) is
clamped to 1 volt above the command voltage to serve as a current limit.
The gate output can be disabled by bringing the CAO/ENBL pin to below
0.8 volts.
BLOCK DIAGRAM
UDG-95098-2
SLUS231 - JUNE 1998
