U4488B

Quasi-Split Sound Circuit and AM Demodulator

Description

The U4488B is an integrated bipolar circuit for full multi-

standard sound IF signal processing in TV/VTR and

Multimedia applications. It supplies AM signals as well

as FM/NICAM sound IF signals and thus allows the de-

sign of a universal sound IF module for various

applications. The U4488B has the same performance like

the U4468B, with the additional feature of a second sym-

metrical IF input.

Features

D

5-V supply voltage; low power consumption

D

Gain-controlled 3-stage wideband IF amplifier

D

Active carrier generation by FPLL principle

(frequency-phase-locked-loop) for true quadrature

demodulation

D

Complete alignment-free AM demodulator

D

Switchable amplitude detector for gain control, which

operates as a peak detector for FM sound and as a

mean level detector for AM sound

D

Two symmetrical IF inputs

Block Diagram

IF1/IF2

S3

11

1

2

IF-Amp

12

Intercarrier

(FM)

4

14

REF

FPLL

V

S

Loop

filter

5

0擄

90擄

VCO

9

8

VCO

IF

FM

IF

AM

15

16

IF-Switch

Mean

3

AGC

Peak

level

13

IF AGC

Mean/peak

7

S1

Mute

AM-Det

6

AF(AM)

10

S2

13789

Figure 1. Block diagram

Ordering Information

Extended Type Number

U4488B

Package

DIP16

Remarks

TELEFUNKEN Semiconductors

Rev. A2, 15-Jan-98

1 (9)

Preliminary Information
