DC Characteristic Adjustable

Transmit and Receive Gain Adjustable

Symmetrical Input of Microphone Amplifier

Anti-clipping in Transmit Direction

Automatic Line-loss Compensation

Symmetrical Output of Earpiece Amplifier

Built-in Ear Protection

DTMF and MUTE Input

Adjustable Sidetone Suppression Independent of Sending

and Receiving Amplification

Speech Circuit with Two Sidetone Networks

Built-in Line Detection Circuit

Integrated Amplifier for Loud-hearing Operation

Anti-clipping for Loudspeaker Amplifier

Improved Acoustical Feedback Suppression

Power Down

Voice Switch

Tone Ringer Interface with DC/DC Converter

Zero Crossing Detection

Common Speaker for Loud-hearing and Tone Ringer

Supply Voltages for all Functional Blocks of a Subscriber Set

Integrated Transistor for Short-circuiting the Line Voltage

Answering Machine Interface

Operation Possible from 10 mA Line Currents

Filters against EMI on Critical I/O

Monolithic

Integrated

Feature Phone

Circuit EMI

Improved

U4090B-P

Applications

鈥?/div>

Feature Phone

Answering Machine

Fax Machine

Speaker Phone

Benefits

鈥?/div>

Savings of One Piezoelectric Transducer

Complete System Integration of Analog Signal Processing on One Chip

Very Few External Components

Fewer Components for EMI Protection

Description

The microcontroller-controlled telephone circuit U4090B-P is a linear integrated circuit

for use in feature phones, answering machines and fax machines. It contains the

speech circuit, tone ringer interface with DC/DC converter, sidetone equivalent and

ear protection rectifiers. The circuit is line powered and contains all components nec-

essary for amplification of signals and adaptation to the line.

An integrated voice switch with loudspeaker amplifier allows loud-hearing or hands-

free operation. With an anti-feedback function, acoustical feedback during loud-hear-

ing can be reduced significantly. The generated supply voltage is suitable for a wide

range of peripheral circuits.

Rev. 4741A鈥揅ORD鈥?9/03
