DS3LIM-SN
DS3/STS-1 Line Interface Module
NRZ Clock/Data Output
TXC-20153D, TXC-20153G
DATA SHEET
FEATURES
鈥?Complete B3ZS analog to NRZ digital DS3/
STS-1 line interface unit in a compact 2.6
square inch, 50-pin DIP Module
鈥?Single +5V power supply
鈥?Analog inputs and outputs are transformer
coupled
鈥?Meets DSX cross connect frame mask
requirements (ANSI Standard T1.102-1993)
鈥?Adaptive equalization for zero to 900 feet of
cable
鈥?Input dynamic range of 20 dB (100mV - 0.95V)
鈥?Meets DS3/STS-1 jitter requirements of Bellcore
Technical References
鈥?Full loopback capability
鈥?Coding violation and loss of signal detection for
received signal
鈥?TXC-20153D has monitor pin for received signal
input. TXC-20153G has pull-up for external
clock input and improved performance margins.
鈥?Speeds time to market for prototype
development
鈥?Eases parts inventory and acquisition
鈥?Eases field maintenance
DESCRIPTION
The DS3/STS-1 Line Interface Module (DS3LIM-SN) is
a complete and compact full duplex analog line to digital
terminal interface. It converts B3ZS-encoded line sig-
nals, in either DS3 asynchronous or STS-1 synchro-
nous format, to and from NRZ data and clock signals. In
addition to the synchronous signal option, this Module
offers other improvements relative to the TranSwitch
DS3 Line Interface Module (DS3LIM, TXC-20049D),
which it can replace in some existing DS3 applications.
Sensitive analog circuitry meets DS3/STS-1 perfor-
mance requirements for signal recovery and transmis-
sion, with direct line connection via on-board
transformers. Integration of functions into a single Mod-
ule frees the user from complex printed circuit board
design and testing for the DS3/STS-1 analog section,
reducing the time required for applications development
and product introduction.
APPLICATIONS
鈥?DS3/STS-1 interface for quick 鈥渢ime to market鈥?/div>
products
LINE SIDE
B3ZS analog input
(from BNC connector)
B3ZS analog output
(to BNC connector)
DS3LIM-SN
TXC-20153D/TXC-20153G
DS3/STS-1 Line Interface
Module
TERMINAL SIDE
NRZ data and
clock out
NRZ data and
clock in
Status
Coding Violation
U.S. Patent No. 5,119,326
U.S. and/or foreign patents issued or pending
Copyright
漏
1998 TranSwitch Corporation
TranSwitch, TXC and XBERT are registered trademarks of TranSwitch Corporation
Control
External reference clock:
44.736 MHz (DS3)
51.840 MHz (STS-1)
Document Number:
TXC-20153-MB
Ed. 2, August 1998
TranSwitch Corporation
鈥?/div>
3 Enterprise Drive
鈥?/div>
Shelton, Connecticut 06484
Tel: 203-929-8810
鈥?/div>
Fax: 203-926-9453
鈥?/div>
www.transwitch.com
鈥?/div>
USA
