-3 Device
Ethernet into STS-3/STM-1 SONET/SDH Mapper
TXC-04226
PRODUCT INFORMATION
FEATURES
鈥?Supports up to eight 10/100 Mbit/s Ethernet ports, each using
a SMII interface
鈥?Supports a single 1000 Mbit/s Ethernet port, using a parallel
GMII interface (lead shared with SMII interfaces)
鈥?Supports Ethernet Management interface for control and
configuration of externally connected PHYs.
鈥?Supports IEEE 802.3 flow control and management statistics
(RMON) on 10/100/1000 Mbit/s Ethernet ports
鈥?Supports Ethernet frame encapsulation/decapsulation
protocols:
鈥?ITU-T G.7041, Generic Framing Procedure (GFP)
鈥?ITU-T X.86/X.85, Link Access Procedure SDH (LAPS)
鈥?ITU-T Q.922, Link Access Procedure Frame Mode (LAPF)
鈥?Performs mapping/demapping of encapsulated Ethernet
frames into/from low order (VT1.5 SPE/VC-12) and high
order (STS-1 SPE/VC-3) virtual concatenated payloads
鈥?Performs mapping/demapping of encapsulated Ethernet
frames into/from a single contiguous concatenated (STS-3c-
SPE/VC-4) payload
鈥?Supports optional LCAS processing (per ITU-T G.7042) for
low and high order virtual concatenated payloads
鈥?Glueless memory interface to external 64/128Mb SDRAMs
鈥?Supports 84/63 VT/TU Low Order POH and
Pointer processing
鈥?Supports High Order POH processing for
STS-1/VC-3/STS-3c/VC-4
鈥?Byte-wide parallel Add and Drop Telecom Bus interfaces
鈥?Supports per-port Ethernet side and SONET/SDH system side
loopback for system level diagnostics
鈥?16-bit wide microprocessor interface, selectable between
Motorola or Intel
鈥?Boundary scan (IEEE 1149.1 standard)
鈥?+ 3.3V and +1.8V power supplies, 5V tolerant I/O leads
鈥?400-lead plastic ball grid array package
(27 mm x 27 mm)
DESCRIPTION
The EtherMap鈩?3 is a highly integrated device that provides for mapping of
10/100/1000 Mbit/s Ethernet into SONET/SDH STS-3/STM-1 Transport
payloads. The device supports connection for up to eight 10/100 Mbit/s
Ethernet ports, using SMII interfaces, or a single 1000 Mbit/s Ethernet port,
using a GMII interface. In the transmit direction, for each port, received
Ethernet frames are encapsulated using either GFP, LAPS or LAPF protocol.
The encapsulated Ethernet frames are then mapped into a configurable num-
ber of virtual concatenated low and high order payloads, such as VT1.5 SPE/
VC-12/STS-1 SPE/VC-3, or a contiguous concatenated payload such as
STS-3c SPE/VC-4. For both low and high order payloads, the required
SONET/SDH POH bytes and encapsulated Ethernet payload are generated
and output using a byte-wide parallel interface in the TranSwitch Telecom
Bus format. The EtherMap-3 supports Drop bus and Add bus timing modes.
In the receive direction, for each Ethernet port, a configurable number of low
and high order payloads are terminated, with complete POH byte processing
for virtual or contiguous concatenated payloads. Using an external SDRAM,
alignment and differential delay compensation for the received low and high
order virtual concatenated payloads is performed. The Ethernet frames are
then decapsulated using GFP, LAPS or LAPF protocol and forwarded to each
Ethernet port.
For both low and high order virtual concatenated payloads, optional stan-
dards based LCAS processing is provided to allow hitless dynamic band-
width adjustments.
In addition to support for full-rate Ethernet transfer, over-subscribed Ether-
net transfers are also supported using back pressure mechanisms in order to
prevents frame loss.
APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
SONET/SDH add/drop and terminal multiplexers
Multi-service access platforms
Next generation Ethernet switches
IP DSLAMS
Integrated access devices
TELECOM BUS SIDE
+1.8V
+3.3V
HO/LO
RING
Ports
HO/LO
POH
Ports
Controls
CLOCKS
(SONET/SDH Ref,
System, One Sec.)
ETHERNET LINE SIDE
DROP Bus
EtherMap-3
Ethernet into STS-3/STM-1
SONET/SDH Mapper
10/100 Mbit/s SMII (Port 1)
/ 1000 Mbit/s GMII
ADD Bus
TXC-04226
10/100 Mbit/s SMII (Port 8)
Microprocessor
Interface
SDRAM
Interface
Boundary
Scan
Ethernet
Management
Interface
U.S. and/or foreign patents issued or pending
Copyright
餂?/div>
2002 TranSwitch Corporation
EtherMap is a trademark of TranSwitch Corporation
TranSwitch and TXC are registered trademarks of TranSwitch Corporation
Document Number:
TXC-04226-MC
Ed. 3, May 2002
TranSwitch Corporation
鈥?/div>
3 Enterprise Drive
鈥?/div>
Shelton, Connecticut 06484
Tel: 203-929-8810
鈥?/div>
Fax: 203-926-9453
鈥?/div>
www.transwitch.com
鈥?/div>
USA
Proprietary TranSwitch Corporation Information for use Solely by its Customers
